DL35 Owner's Manual
DL TRUCK LOADER VACUUM Owner's Manual
INTAKE
HOSE REPLACEMENT KIT
Standard on DL units. 14" x 10'
(356mm x 3.0m)
14" Hose P/N 792208
IMPORTANT- READ CAREFULLY BEFORE USE AND KEEP FOR FUTURE REFERENCE
Part No 792500
DL3500
Beginning Serial #: 100515001
Accessories
EXHAUST
EXHAUST HOSE KIT
8" x 5' (203mm x 1.5m) flexible hose
increases exhaust distance. 8" x 5'
(203mm x1.5m) flexible steel hose
increases exhaust distance.
8" Flexible Hose P/N 791107
8" Flexible Steel Hose P/N 791106
Original Instructions
1
TRAILER
TRAILER DL
Heavy duty spring axle trailer
designed for towing your DL. Allows
unit to be mounted for pickup from
rear.
P/N 791152
Form No F102015D
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Billy Goat DL3500
Summary of Contents for Billy Goat DL3500
- Page 1 DL35 Owner’s Manual DL TRUCK LOADER VACUUM Owner's Manual DL3500 Beginning Serial #: 100515001 Accessories INTAKE EXHAUST TRAILER HOSE REPLACEMENT KIT EXHAUST HOSE KIT TRAILER DL Heavy duty spring axle trailer Standard on DL units. 14" x 10' 8" x 5' (203mm x 1.5m) flexible hose designed for towing your DL.
-
Page 2: Table Of Contents
DL35 Owner’s Manual CONTENTS SPECIFICATIONS AND SOUND/VIBRATION INSTRUCTION LABELS PACKING CHECKLIST ASSEMBLY OPERATION MAINTENANCE TROUBLESHOOTING ILLUSTRATED PARTS & PARTS LIST 11-12 DECLARATION OF CONFORMITY 13-15 Part No 792500 Form No F102015D... -
Page 3: Specifications And Sound/Vibration
DL35 Owner’s Manual SPECIFICATIONS DL3500V Engine: HP 35 (26.1kW) Engine: Model 6134770222 G1 Engine: Type Briggs and Stratton Vanguard Engine: Fuel capacity 6 gal. (22.7 L) REMOTE TANK Engine: Oil capacity 2.4 qt. (2.3 L) Total Unit weight: 368 lbs (167 kg) Max operating slope 74 7/8”... -
Page 4: Instruction Labels
INSTRUCTION LABELS ® The labels shown below were installed on your BILLY GOAT DL Vacuum. If any labels are damaged or missing, replace them before operating this equipment. For your convenience in ordering replacement labels, part numbers are included in the Illustrated Parts List. -
Page 5: Packing Checklist
DL35 Owner’s Manual PACKING CHECKLIST Your Billy Goat is shipped from the factory in one carton and is completely assembled except for the exhaust elbow, nozzle, handle loop for nozzle, hose booms, hose bands, hose coupler, hose clamps and related hardware. -
Page 6: Assembly
(see Fig. 1). both sides MOUNTING: Fig. 2 illustrates the mounting position to the trailer (Billy Goat Part No. 791133) available from your Billy Goat dealer. The unit is Fig. 1 only mounted one way. MOUNTING EXHAUST ELBOW (See Fig. 3) NOTE: this process requires two people, one to support the exhaust elbow and one to attach plates and hardware. -
Page 7: Operation
DL35 Owner’s Manual OPERATION VACUUMING OPERATION IMPORTANT: With the machine off and spark plug disconnected check the condition of the replaceable liner before every use and replace if necessary. EXHAUST DIRECTION & DISTANCE: Exhaust direction and distance are controlled by the rotation of the exhaust elbow. -
Page 8: Maintenance
3/4"-16 x 3" bolt and thread it into the nut that is welded onto the center of the impeller and tighten slowly to push the impeller off the crankshaft. NOTE: The 3/4"-16 x 3" bolt can be ordered from your local Billy Goat Dealer (Part No. 440192). Fig. 7 8. - Page 9 DL35 Owner’s Manual WIRING DIAGRAM BATTERY CARE (For Electric-Starting Models) Proper care can extend the life of a battery. Follow these recommendations to ensure your battery’s best performance and long life: • Do not allow the battery charge to get too low. If the machine is not used, charge the battery every 4 – 6 weeks. Operate the engine for at least 45 minutes to maintain proper battery charge.
-
Page 10: Troubleshooting
DL35 Owner’s Manual TROUBLESHOOTING Problem Possible Cause Solution Abnormal vibration Loose or out of balance impeller or Check impeller and replace if loose engine. necessary. Check engine. Will not vacuum or has poor Nozzle buried in debris. Clogged Withdraw nozzle from debris pile. vacuum performance hose or exhaust. -
Page 11: Illustrated Parts & Parts List
DL35 Owner’s Manual DL35 PARTS DRAWING 36 37 TO ENGINE TO SAFETY SWITCH LOCATED ON INTERIOR OF HOUSING TO TANK TO TANK LINE OVERFILL LINE TO FUEL TANK TO PURGE BATTERY NOT SUPPLIED Part No 792500 Form No F102015D... - Page 12 DL35 Owner’s Manual DL35 PARTS LIST DL35 PART DL35 PART ITEM NO DESCRIPTION ITEM NO DESCRIPTION ENGINE BRIGGS VANGUARD 35 HP 792228 NUT LOCK 5/16"-18 HEX ZP 8160002 BOOM HOSE WA 791113 BOLT CARRIAGE 5/16"-18 X 3 1/2" ZP 8024050 INTAKE HOUSING WA W/LABELS 792600 SPACER 3/8"...
-
Page 13: Declaration Of Conformity
DL35 Owner’s Manual Руccкий Latviešu English Suomi Slovenščina български език Français Nederlands Čeština Slovák Ελληνικά Norsk Svenska Dansk Hrvatski Polski Türkçe Deutsch Magyar Português Română Español Italiano Lietuvių eesti keel Δήλωση συμμόρφωσης ΕΚ Deklaracja zgodności UE EC Declaration of Conformity Декларация... - Page 14 DL35 Owner’s Manual Directive: 2006/42/EC Irányelv: 2006/42/EC Diretiva: 2006/42/EC Директива: 2006/42/EC Οδηγία: Директива: 2006/42/EC 2006/42/EC Směrnice č. 2006/42/EC Direktiva: 2006/42/EC Directiva: 2006/42/EC Direktiv: 2006/42/EF Direttiva: 2006/42/EF Direktiva: 2006/42/EF Richtlinie: 2006/42/EG Direktyva: 2006/42/EG Smernica: 2006/42/EG Direktīva: Directriz: 2006/42/EC 2006/42/EC Direktiv: 2006/42/EC Direktiiviga: 2006/42/EÜ...
- Page 15 DL35 Owner’s Manual (1) ISO 5395-1:2013 F.7 (EN 4871:1996) (2) ISO 5395-1:2013 G.8 (EN 12096:1997, D.1) Miejsce produkcji / Osoba odpowiedzialna za Manufacturing Place / Keeper of Documentation Τόπος κατασκευής / Υπεύθυνος τήρησης αρχείων Място на производство / Архивар przechowywanie dokumentów τεκμηρίωσης...
