Billy Goat KD512, KD512HC, KD512HCS Operator Owner's Manual

Billy Goat KD512, KD512HC, KD512HCS Operator Owner's Manual

The powerful kd vacuum
Hide thumbs Also See for KD512, KD512HC, KD512HCS:
Table of Contents

Advertisement

Quick Links

2
OPTIONAL ACCESSORIES
SHREDDER KIT
P/N 890209.
Shreds leaves, reducing total
volume.
ON BOARD VACUUM
HOSE KIT
P/N 890041. 4"
(102mm)
7'
(2.13m)
For vacuuming in hard to
reach areas.
NOZZLE WEAR PLATES
P/N 890413.
(STD. ON KD512HCS)
Extends nozzle life when
used along curbs and hard
surfaces.
OPTIONAL DEBRIS BAGS
STANDARD TURF PRO
DEBRIS BAG
P/N 890028.
For use in leaves and grass in
non-dusty conditions.
DEBRIS BAG COVER
P/N 900801
Directs dust downward away
from operator.
ZIPPERLESS QUICK BAG
P/N 890309
For non dusty conditions that
are damaging to zippers.
CASTER KIT
P/N 890412
For use on hard surface
3
ENGINE: H.P.
ENGINE: TYPE
ENGINE: FUEL CAP
ENGINE: OIL CAP
WEIGHT: UNIT
WEIGHT: SHIPPING
WEIGHT: ENGINE
UNIT SIZE:
Part No. 890033
1
x
Operator Owner's Manual

Specifications

OVERALL LENGTH: 62"(1.57m) OVERALL WIDTH 26.75" (0.68m)
T h a n k Y o u f o r S e l e c t i n g
The Powerful KD VACUUM
KD512, KD512HC, KD512HCS
KD512
KD512HC
5.0 (3.73 kW)
5.5 (4.11 kW)
B&S QUANTUM
HONDA OHC
1.5qt. (1.4 L)
1.16qt. (1.1 L)
0.63qt. (0.6 L)
0.58qt. (0.6 L)
98# (44.5 kg)
99# (45.0 kg)
120# (54.4kg)
124# (56.0 kg)
24.38# (11.05 kg)
22# (10.0 kg)
Page 1 of 8
KD512HCS
5.5 (4.11 kW)
HONDA OHC
1.16qt. (1.1 L)
0.58qt. (0.6 L)
116# (52.6 kg)
138# (63.0 kg)
22# (10.0 kg)
OVERALL HEIGHT 42" (1.07m)
Form No. F042805A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KD512, KD512HC, KD512HCS and is the answer not in the manual?

Questions and answers

Related Manuals for Billy Goat KD512, KD512HC, KD512HCS

Summary of Contents for Billy Goat KD512, KD512HC, KD512HCS

  • Page 1: Specifications

    Part No. 890033 T h a n k Y o u f o r S e l e c t i n g The Powerful KD VACUUM Operator Owner's Manual KD512, KD512HC, KD512HCS Specifications KD512 5.0 (3.73 kW) 5.5 (4.11 kW) B&S QUANTUM...
