Introducing the RS-232 to Bluetooth
The RS-232 to Bluetooth converter allows any device with
an RS-232 port to communicate wirelessly.
Features and Benefits
Replaces RS-232 cable
Full Bluetooth 2.0 support +EDR
Easy to configure baud rate and master or slave role
selectable
Supports baud rates up to 115.2 K bps
300 feet ( Enhanced Antenna ); CLASS 1
System Requirements
Pentium II or equivalent PC
Windows 2000 and above
Package Contents
RS-232 to Bluetooth Converter with Antenna
Power adapter (5V, 500mA)
Software CD
Quick Installation Guide
Serial Number Sticker
For future product return or exchange, this serial number
is required. Please keep if for your reference.
04-0485A
RS-232 to Bluetooth
Quick Installation Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ID-SB0011-S1 and is the answer not in the manual?

Questions and answers

Summary of Contents for SIIG ID-SB0011-S1

  • Page 1 RS-232 to Bluetooth Quick Installation Guide Introducing the RS-232 to Bluetooth The RS-232 to Bluetooth converter allows any device with an RS-232 port to communicate wirelessly. Features and Benefits • Replaces RS-232 cable • Full Bluetooth 2.0 support +EDR • Easy to configure baud rate and master or slave role selectable •...
  • Page 2: Led Indicators

    Layout LED Indicators See Figure 2 on the next page for the location of the LEDs. Red: Power indicator - on all the time. • Green: Before connecting to synchronize between • the serial device and the BT RS232 Config Tool software, the green LED will be blinking.
  • Page 3: Rs-232 (Serial)

    Antenna Connector Antenna Connector The connector is a standard Reverse SMA jack. Simply connect it to a 2.0dBi, 50 Ohms impedance dipole antenna to support 2.4 GHz frequency. (The Antenna is changeable for high gain Antenna), see Figure 2. RS-232 (Serial) Connect the RS-232 port into the device as you would with any computer and serial device, see Figure 3.
  • Page 4: Hardware Installation

    Set-up Button Set-up button The purpose of the Set-up Button is for synchronizing between RS-232 to Bluetooth Converter and BT RS232 Config Tool software. Hardware Installation Connect the RS-232 to Bluetooth Converter to COM Port of PC. Connect the DC power adapter and jack into power outlet and DC-in outlet.
  • Page 5: Bt Rs232 Config Tool Installation & Setup

    BT RS232 Config Tool Installation & Setup When setting up RS-232 to Bluetooth Converter for the first time, you have to install and run BT1.exe as BT RS232 config tool first in your computer device. The utility CD is enclosed in the device box. Before you use RS-232 to Bluetooth Converter, you have to pair it with another E- BT232 device.
  • Page 6 • SB-232 Config Tool Parameters Configuration Figure 6 After double click the icon of BT1 as BT RS232 Config Tool, the configuration screen will be pop-up as the above picture. A. COM Port Select COM port number, you have to avoid the port conflict with other device in computer and use available port number B.
  • Page 7 E. PIN Code Device uses a PIN Code to identify during connecting and communication. F. Role Role is for identifying the role of the device as a master or slave. Select Master, for DTE mode, for Data Terminal Equipment (such as a PCs). Select Slave for DCE mode, for Data Communication Equipment (such as a Modem).
  • Page 8 Apply Connect Figure 7 After finish the parameters configuration, click the Connect icon in BT RS232 Config Tool screen and immediately press the Set-up button on the left side of the device. Connect is changed to Disconnect when connection is successfull.
  • Page 9 Apply Write Click Write, to save all parameters after configuring into the BT RS232 Config Tool. Apply Read Figure 8 Figure 9...
  • Page 10 To click the item of Read, the meaning is to load all parameters as last time saving from the BT232 Config Tool. The local address will be updated the real device address at first time. RS-232 Pin Assignment The pin assignment scheme for a 9-pin male connector on a DTE is given below Pin1: X Pin 2: TXD...
  • Page 11: Technical Support And Warranty

    Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. Step 2: After obtaining an RMA number, ship the product.
  • Page 12 6078 Stewart Avenue Fremont, CA 94538-3152, USA RS-232 to Bluetooth Converter is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Pentium is a registered trademark of Intel Corporation.
