Installation Guide
For Model:
WH44OSB5L
APPROVED FOR USE
IN DAMP LOCATIONS
net weight of fan: 16.53 lb. (7.5 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Wiring. pg. 4
Fan Assembly. pg. 5
Motor Housing Assembly. pg. 5
Blade Assembly. pg. 6
Testing Your Fan. pg. 8
Troubleshooting. pg. 9
Parts Replacement. pg. 9
Warranty. pg. 9
PRINTED IN CHINA
Advertisement
Table of Contents
Related Manuals for Litex WH44OSB5L
Summary of Contents for Litex WH44OSB5L
-
Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Model: WH44OSB5L Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pgs. 3 - 4 Wiring. -
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS. -
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. -
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that the hanging location allows the blades a inches clearance of 7ft. (2.13m) from the floor and 30in. 7 feet (76cm) (76cm) from any wall or obstruction. (2.13m) This fan is suitable for room sizes up to 144 square feet (13.4 square meters). -
Page 5: Wiring
4. Hanging Bracket Installation. (cont.) Install hanging bracket to outlet box using original screws, spring washers and flat washers provided with new or original outlet box.* Pull electrical wiring from outlet box through center hole in the hanging bracket. hanging *NOTE: It is very important that you use the bracket proper hardware when installing the hanging... -
Page 6: Fan Assembly
6. Fan Assembly. hanging Remove motor assembly from j-hook on bracket hanging bracket. Lift motor assembly to j-hook hanging bracket and carefully push wiring and wire connectors into outlet box. Align holes in top of motor assembly with bolts in hanging bracket and push up so that motor bolts come through holes. -
Page 7: Blade Assembly
8. Blade Assembly. Locate fifteen 3C-Clips™ in one of the hardware packs. Hold a blade arm up to a blade and align motor the preassembled blade screw posts on the housing blade arm with the holes on the blade. [NOTE: Make sure to attach blade arm so the flat side of the blade faces UP.] Press on blade firmly until blade screw posts... - Page 8 9. Light Kit Assembly (Optional). (cont.) switch housing cap Locate BLACK (or BLUE) and WHITE wires in hex nut switch housing labeled "LIGHT." Remove and lock washer center cap threaded rod discard plastic that holds these 2 wires together. light kit fitter Remove hex nut and lock washer from threaded rod at top of light kit fitter.
-
Page 9: Testing Your Fan
10. Testing Your Fan. It is recommended that you test fan before finalizing installation. Restore power from reverse circuit box and light switch (if applicable). Test switch motor housing fan speeds with the pull chain on switch housing located to the RIGHT of the reverse switch (labeled FAN). -
Page 10: Troubleshooting
Service at 1-800-527-1292 to arrange for return of fan. 1. Check wall switch to fan. Return fan, shipping prepaid, to Litex Industries, Ltd. We will 2. Verify that reverse switch is set completely in repair or ship you a replacement fan, and we will pay the either direction.
