Federal regulations require all ceiling
fans with light kits manufactured or
imported after January 1, 2009, to limit
total wattage consumed by the light kit
to 190W. Therefore, this fan is equipped
with a wattage limiting device.
Installation Guide
For Model:
E-UB48BC4C1
E124404
net weight of fan: 12.02 lb. (5.45 kg)
READ THESE INSTRUCTIONS
AND SAVE THEM FOR FUTURE USE

Table of Contents:

Wiring. pg. 5
Warranty. pg. 8
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-UB48BC4C1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Litex E-UB48BC4C1

Summary of Contents for Litex E-UB48BC4C1

  • Page 1: Table Of Contents

    190W. Therefore, this fan is equipped with a wattage limiting device. Installation Guide For Model: E-UB48BC4C1 Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation.

  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. Read all instructions and safety information carefully before installing your fan and save these instructions. CAUTION: To avoid personal injury, the use of gloves may be necessary while handling fan parts with sharp edges.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.

  • Page 4: Installation Preparation

    3. Installation Preparation. To prevent personal injury and damage, ensure blade edge that the hanging location allows the blades a clearance of 10ft. (3.05m) from the floor and 30in. inches (76cm) from any wall or obstruction. 10 feet (76cm) This fan is suitable for room sizes up to 225 (3.05m) square feet (20.9 square meters).

  • Page 5: Fan Assembly

    5. Fan Assembly. Loosen canopy set screw and lower canopy to expose hanging bar. Separate electrical wiring and safety cable from rubber band. Lift fan onto j-hook hanging bracket and slide rubber bushing over hook. Make the j-hook wiring connections as shown in Section 6 on hanging bracket the following page.

  • Page 6: Wiring

    6. Wiring. CAUTION: Be sure outlet box is properly grounded white supply wire and that a ground wire (GREEN or Bare) is present. black supply wire Make sure all electrical connections comply with Local Codes or Ordinances and the National safety cable Electrical Code.

  • Page 7: Canopy Assembly

    7. Canopy Assembly. Lift canopy over hanging bracket until it touches the ceiling. Tighten the canopy set screw to secure canopy. canopy canopy set screw 8. Blade Assembly. Locate 1 rubber cushion at the top of the motor housing. Remove the 2 larger screws and washers but leave rubber cushion intact.

  • Page 8: Light Kit Assembly

    9. Light Kit Assembly. Install 1 candelabra base 60 watt max. bulb (included). Important: When replacing bulb, please allow bulb and glass shade to cool before reverse switch touching. Partially loosen 3 thumbscrews at bottom of motor housing and raise glass shade to motor motor housing.

  • Page 9: Troubleshooting

    Service at 1-800-527-1292 to arrange for return of fan. 1. Check wall switch to fan. Return fan, shipping prepaid, to Litex Industries, Ltd. We will 2. Verify that reverse switch is set completely in repair or ship you a replacement fan, and we will pay the either direction.
