Installation Guide
For Models:
CC52AB5C3
CC52WW5C3
E124404
net weight of fan: 15.2 lbs. (6.9 KG)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Hanging Bracket Installation. pg. 3
Preparation for Wiring. pg. 4
Wiring. pg. 4
Fan Assembly, Step Two. pg. 5
Motor Housing Assembly. pg. 5
Blade Assembly. pg. 6
Testing Your Fan. pg. 7
Troubleshooting. pg. 8
Parts Replacement. pg. 8
Warratny. pg. 8
PRINTED IN CHINA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Litex CC52AB5C3
Summary of Contents for Litex CC52AB5C3
-
Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Models: CC52AB5C3 Table of Contents: CC52WW5C3 Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Preparation for Wiring. -
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. Read all instructions and safety information carefully before installing your fan and save these instructions. -
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. -
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches that the hanging location allows the blades a 7 feet (76cm) (2.13m) clearance of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. 12ft. -
Page 5: Preparation For Wiring
5. Preparation for Wiring. hanging bracket slot Remove 4 motor mounting screws and washers from underside of motor assembly. Leave rubber cushions in place. Lift motor assembly to hanging bracket and place one end of motor assembly in hanging hanging bracket slot. This will allow motor bracket motor assembly assembly to hang out of the way while wiring. -
Page 6: Fan Assembly, Step Two
7. Fan Assembly. hanging bracket Remove motor assembly from temporary opening hanging slot in hanging bracket. Carefully push wiring and wire nuts into outlet box. Slide one end of motor assembly through hanging one of the openings in the hanging bracket slot opening... -
Page 7: Blade Assembly
9. Blade Assembly. Time Saver: Washers for blade screws can be set motor housing on each blade screw prior to installing blades. Locate 15 blade attachment screws and washers in one of the hardware packs. Hold blade arm up blade attachment to blade and align holes. -
Page 8: Testing Your Fan
10. Light Kit Assembly (Optional). (cont.) motor housing If necessary, pull pre-cut section of plastic covering off wire ends. Connect WHITE wire from switch housing to WHITE wire from light kit fitter. Connect BLUE wire from switch housing to BLACK wire from light kit fitter. -
Page 9: Troubleshooting
Service at 1-800-527-1292 to arrange for return of fan. 1. Check wall switch to fan. Return fan, shipping prepaid, to Litex Industries, Ltd. We will 2. Verify that reverse switch is set completely in repair or ship you a replacement fan, and we will pay the return shipping cost.
