Operation
1.
Connect the probe to the monitor.
2.
Press the Power button to turn the monitor on.
3.
Maneuvere the probe into position to view the area to be examined. The probe can be
bent into the shape of the area to be examined. Optimum focus distance is 2 to 6cm (0.79
to 2.3")
4.
Optimum focus distance is probe dependent, but the typical range is 2 to 6cm
Zoom
Press the
or
Light Intensity
Press and release the
intensity
Note: the camera LEDs become warm when set to maximum intensity
Taking a Picture
Press the
display when a picture is taken.
Recording a Video
Press the
when a video is being recorded. Press the
recorded on the video via the microphone on the bottom of the monitor.
Note: The bottom access cover must be removed for audio recording.
The IP67 waterproof rating applies to the monitor when the bottom panel access cover is fully in
place.
Display Rotation
Press the
button to rotate the display 90 degrees.
Installing probe accessories
Three accessories (mirror, anti-snag tip and magnet) are supplied with each probe.
Attach the accessory by unscrewing the probe ring and screwing on the attachment.
zoom buttons to increase or decrease the display resolution from 1X to 2X.
or
button to take and store a picture into memory. The
button to start recording a video. The
buttons to increase or decrease the camera LED light
button to stop the recording. Audio will be
5
icon will appear on the
icons will appear on the display
HDV600-en-GB_V3.0 1/18
