Setup
Battery Charging and Status Indication:
Note: A fully charged battery will allow approximately 5 hours of continuous use.
1. Turn the meter off and then connect the AC adaptor to charge the meter.
2. After several hours, turn the meter on. The battery icon will indicate either:
A: Fully charged
B: Charge in progress
3. If the battery is charged, remove the AC adaptor and observe that the fully charged 4 bar
icon
4. If the battery icon indicates less than 4 bars, turn the meter off and continue charging.
5. Always wait for a full fully charged indication to maximize operation time and to maintain
battery health.
Note: The battery will not properly charge if the meter is on during the charging cycle.
Startup
1. Insert the SD card into the bottom SD slot
2. Press the Power button to turn the monitor on. The battery icon will briefly appear indicating
the battery condition.
3. Press OK to open the setup MENU
Press the ▲ or ▼ button to scroll through the
4.
MENU selections.
5. Press OK to open the highlighted selection.
Press the ▲ or ▼ button to scroll through the
6.
items in an open menu item.
Press the ▲ or ▼ buttons to increase or
7.
decrease the selected value.
8. After there has been a change, press the OK button to save the change or the ESC button to
exit without the change.
Note: After 10 seconds of inactivity, the Setup menu will exit without storing changes.
MENU Description:
DELETE ALL:
DATE/TIME SETUP:
LANGUAGE:
VIDEO FORMAT:
AUTO POWER OFF:
INPUT SOURCE:
appears.
Erase all stored pictures and videos
Set the date (year/month/day), time (hour:minute:second) and display
on/off
Set the menu display to any one of 21 languages.
Set the video output to NTSC or PAL format.
Set the APO to 5, 10, 15, 30 minutes or DISABLE.
Set Direct or Wireless.
