Installation Instructions

INSTALLATION

The MSM1U/MTM1U/LSM1U/LTM1U mounts are designed to
be mounted to a bare 8" concrete, 8"x8"x16" concrete block; or
2" x 4" wood studs (16" on center for MSM1U/MTM1U, and 16"
or 24" on center for LSM1U/LTM1U) wall covered by drywall of
5/8" maximum thickness.
The MTM1U and LTM1U have brackets which allow the TV to
be tilted. The MSM1U and LSM1U have static brackets which
keep the TV in an upright position.
Locate Mounting Site
WARNING:
IMPROPER INSTALLATION CAN LEAD TO
MOUNT FALLING CAUSING SEVERE PERSONAL INJURY
OR DAMAGE TO EQUIPMENT! It is the installers responsibility
to make certain the structure to which the mount is being
attached is capable of supporting five times the combined
weight of all components located on the mount, not to exceed
125 lbs (56.7 kg) for the MSM1U/MTM1U OR 200 lbs (90.7 kg)
for the LSM1U/LTM1U.
NOTE:
Proceed to either the Installing to a Wood Stud Wall
section or the Installing to a Concrete Wall section.

Installing to a Wood Stud Wall

1. Determine the center of the TV screen, and where it should
be located on the wall.
2. Locate the closest stud to the left and right of the selected
location.
NOTE:
If the screen area lies over a stud, use that stud and the
stud to either the left or right of it.
3. Line up the notches on mount (CC) with center of screen
marking to determine vertical center. (See Figure 1)
4. Measure up 8" (203.2mm) from the center point to mark
location of the upper mounting slots.
Center of screen
Figure 1
5.
6.
7.
8.
9.
10. Tighten lag bolts to secure mount (CC) to wall at upper
13
11. Mark the attachment points for the lower mounting slots,
8"
(203.2mm)
12. Drill 7/32" (5.5mm) pilot holes at markings for lower
13. Use two 5/16 x 2-1/2" flanged lag bolts (N) and two 5/16"
14. Slide rails to approximate center of screen location.
15. Proceed to Locking Rails section.
Vertical center
of mount
(MSM1U shown)
MSM1U/MTM1U/LSM1U/LTM1U
Using a level, mark the wall on each stud to attach the
mount through the upper mounting slots. (See Figure 2)
Drill one 7/32" (5.5mm) pilot hole in each stud.
Partially install two 5/16 x 2-1/2" flanged lag bolts (N) into
pilot holes but do not tighten to wall.
Hang mount (CC), aligning upper mounting slots over lag
bolts and adjust side-to-side for proper location.
Place one slotted washer (Q) over each flanged lag bolt.
(See Figure 2)
mounting slots.
7
9
(Q) x 2
10
(CC)
(Q) x 2
(N) x 2
13
Figure 2
making sure the attachment points are located on the studs.
(See Figure 2)
mounting holes. (See Figure 2)
slotted washers (Q) to attach the mount to the wall through
the lower mounting holes. (See Figure 2)
(N) x 2
5 6
11
12
(MSM1U shown)
7
