MSM1U/MTM1U/LSM1U/LTM1U

TOOLS REQUIRED FOR INSTALLATION

#2
PARTS
Universal Hardware Kit
M6x25mm
[Included in hardware box]
Wall Mounting Hardware Kit
P (4)
N (4)
UX10x60mm
5/16 x 2-1/2"
X (4)
[Wall cover]
Y (1)
Z (1)
[left]
[right]
[Interface brackets]
(MSM1U/LSM1U Only)
6
7/32" (5.5mm) Wood Stud
3/8" (9.5mm) Concrete
A (4)
B (4)
M4x20mm M4x25mm
M4x12mm
I (4)
J (4)
K (4)
M8x12mm M8x20mm
MSM1/LSM1 Mount Hardware Kit
R (1)
1/8"
Q (4)
[Slotted
washer]
[Included in hardware box]
BB (1)
AA (1)
[right]
[left]
[Interface brackets]
(MTM1U/LTM1U Only)
(included)
E (4)
C (4)
D (4)
M5x12mm M5x20mm
MA (8)
L (4)
[Nesting
M8x30mm
spacer]
S (1)
3/16"
U (2)
3/8-16 x 3/4"
T (4)
1/4-20 x 3/4"
CC (1)
[MSM1U/MTM1U
mount]
Installation Instructions
1/8"
G (4)
F (4)
M6x12mm
M5x25mm
MB (4)
[Universal washer]
MTM1/LTM1 Mount Hardware Kit
S (1)
R (1)
3/16"
1/8"
W (2)
1/4-20 1/4-20 x 3/4"
V (2)
1/4-20 x 1"
[Included in hardware box]
OR
CC (1)
[LSM1U/LTM1U
mount]
3/16" x 10"
(included)
H (4)
M6x20mm
U (2)
3/8-16 x 3/4"
T (4)
