- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Installationsanleitung Instruções de Instalação FUSION MEDIUM HEIGHT ADJUST Istruzioni di installazione Installatie-instructies Instructions d´installation FLAT PANEL MOUNTS MSM/MTM Series...
-
Page 2: Installation Instructions
It is the installer’s responsibility to make sure the combined weight of all components located between the MSM/MTM up to (and including) the display does not exceed 125 lbs (56.7 kg) for dual stud attachment, and 75 lbs (34.0 kg) for single stud... - Page 3 UP/DOWN ADJUSTMENT EACH SIDE 1.52 38.5 191.2 1.00 25.4 [12.7] UP/DOWN ADJUSTMENT EACH SIDE 2.00 50.8 7.53 191.2 1.00 25.4 MSM/MTM Series 7.53 16.50 15.75 419.1 15.10 383.4 1.96 VERTICAL 49.8 SPACING 15.75 [400] 16.50 15.10 1.98 383.4 50.3 VERTICAL SPACING 12°...
- Page 4 À la main Hex-Head Wrench Llave de cabeza hexagonal Sechskantschlüssel Chave de cabeça sextavada Chiave esagonale Zeskantsleutel Clé à tête hexagonale MSM/MTM Series Pencil Mark Marcar con lápiz Stiftmarkierung Marcar com lápis Segno a matita Potloodmerkteken Marquage au crayon Drill Hole...
-
Page 5: Tools Required For Installation
MSM/MTM Series TOOLS REQUIRED FOR INSTALLATION 7/32" (5.5mm) Wood Stud 5/16" (7.9mm) Concrete PARTS A (1) [Included with MSM6XXX/MTM6XXX Models Only] Custom J (1) [Used on MSMU/MTMU Models Only] MSM6XXX/ MTM6XXX Hardware J1 (8) M4x16mm J4 (6) M5x16mm M5x20mm J7 (6) - Page 6 The MTM and MSM have been designed to be mounted directly onto either a wood stud or concrete wall. The MTM has brackets which allow the TV to be tilted. The MSM has static brackets which keep the TV in an upright position.
- Page 7 Install an anchor (K1) into each pilot hole using a hammer. Use two 5/16 x 2-1/2" lag bolts (K3) and two 5/16" flat washers (K2) to attach top of mount to anchors in wall. MSM/MTM Series ELECTRICAL SHOCK HAZARD! CUTTING EXPLOSION AND FIRE HAZARD! CUTTING...
- Page 8 MSM/MTM Series Mark the attachment points for the lower mounting slots. (See Figure 4) Drill one pilot hole at each marking for lower mounting holes. (See Figure 4) 10. Install an anchor (K1) into each pilot hole using a hammer.
- Page 9 (See Figure 8) Center Line (CL) NEVER place both interface brackets to one side of the wall mount center line (CL)! Both interface brackets must NEVER be located to one side of the wall bracket! MSM/MTM Series Pullstraps Figure 8...
- Page 10 MSM/MTM Series Pullstraps (Screen not shown for clarity) Figure 9 Hang top hook of interface brackets onto the top bar of the mount. (See Figure 9) NOTE: The screen initially installs into the "kickstand mode" to allow easy cable access.
- Page 11 Installation Instructions MSM/MTM Series...
- Page 12 MSM/MTM Series Chief Manufacturing, a division of Milestone AV Technologies 8831-000024 2008 Milestone AV Technologies www.chiefmfg.com 09/08 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands...
