I N S T A L L A T I O N I N S T R U C T I O N S
LCD Swivel Stand
MSS6000

Advertisement

loading
Need help?

Need help?

Do you have a question about the MSS6000B and is the answer not in the manual?

Questions and answers

Summary of Contents for CHIEF MSS6000B

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S LCD Swivel Stand MSS6000...
  • Page 2 ®Chief is a registered trademark of Milestone AV Technologies. Reinforce the structure as required before installing the All rights reserved.
  • Page 3 Installation Instructions MSS6000 LEGEND Pencil Mark Tighten Fastener Marcar con lápiz Apretar elemento de fijación Stiftmarkierung Befestigungsteil festziehen Marcar com lápis Apertar fixador Segno a matita Serrare il fissaggio Potloodmerkteken Bevestiging vastdraaien Marquage au crayon Serrez les fixations Drill Hole Loosen Fastener Perforar Aflojar elemento de fijación...
  • Page 4 MSS6000 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 3/16" 5/32" 3/8" (Provided) (Provided) PARTS A (1) B (5) D (1) C (1) .5x.5x.203 3/16" 5/32"...
  • Page 5 Installation Instructions MSS6000 INSTALLATION Remove slide plate assembly from the base by removing four 5/16-18 x 3/4" button head cap screws, and four 1/4" flat washers. (See Figure 3) Mount Installation Free Standing (not anchored) Applications Only: NOTE: Do not perform this step if you are going to anchor the stand to a surface.
  • Page 6 150 lbs (68.04 kg). If an interface bracket for the display being mounted needs to be obtained, or additional assistance is required, contact a Chief Customer Service representative. CAUTION: TURNING DISPLAY CAN CAUSE DAMAGE TO SURROUNDING OBJECTS. Make certain location...
  • Page 7 Installation Instructions MSS6000 Remove bolt or padlock if used May remove pin and nut and move to lower holes Pin in "Closed" position - move to "Open" position to remove display A padlock or bolt may be placed through latch holes Figure 7 Removing Display from Mount Remove bolt or padlock from faceplate (if used).
  • Page 8 MSS6000 Installation Instructions ADJUSTMENTS Display Roll Adjustment The MSS6000 provides limited display roll adjustment for the Display Height Adjustment purpose of leveling the display. To level the display: CAUTION: Displays are fragile. Allowing the display to drop Loosen upper and lower roll adjustment nuts. (See Figure 10) to bottom of stand may result in damage to the display.
  • Page 9 Installation Instructions MSS6000 Display Swivel Tension Adjustment Display swivel tension is pre-set at the factory. Swivel tension will vary depending on the weight of display being mounted. If swivel tension adjustment is required: Disconnect all cords and cables from display. Follow steps in Removing Display from Mount section.
  • Page 10 MSS6000 Installation Instructions Option B Option B uses the cable access at the center of the MSS-6000 and then routes the cables across the mounting surface and out the rear cable access slot in the back of the mount. (See Figure 14) Cable Access Rear...
  • Page 11 Installation Instructions MSS6000...
  • Page 12 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 Chief Manufacturing, a products division F +31 (0)40 2668615 of Milestone AV Technologies Asia Pacific A Room 24F, Block D, Lily YinDu International Building 8800-000057 RevC LuoGang, BuJi Town, Shenzhen, CHINA.
