Summary of Contents for CHIEF MSBV
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S VESA Interface Bracket Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description MSBV...
-
Page 2: Installation Instructions
WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components attached to the MSBV does not exceed 125 lbs (56.7 kg). -
Page 3: Dimensions: Inches
Installation Instructions MSBV DIMENSIONS 17.00 300x200 400x200 0.81 MOUNTING BUTTONS FIT INTO WITH SPACERS TEARDROP SLOTS ON MOUNT 0.31 0.38 0.75 1.97 0.75 0.38 9.63 100x100 200x200 MOUNTING PATTERNS USE 200x100 BUTTONS ATTACHED DIRECTLY TO 300x100 THE BACK OF THE DISPLAY 0.20... -
Page 4: Tools Required For Installation
D (8) M5 x 12mm M5 x 25mm E (8) F (8) M5 x 30mm M5 x 45mm P (1) [MSBV bracket] Bag C G (8) H (8) M6 x 12mm M6 x 25mm J (8) K (8) M6 x 30mm... - Page 5 100 x 100mm Pattern Select four properly sized M4 screws from Bag A. Attach the MSBV bracket (A) using the hole pattern on back of display and holes noted at "X". (See Figure 2) Long screw from...
- Page 6 Select eight properly sized M4 screws from Bag A. Select six M5 or M6 screws from Bag B or Bag C. Attach the MSBV bracket (A) using the hole pattern on back Attach the MSBV bracket (A) using the hole pattern on back of display and holes noted at "X".
- Page 7 Installation Instructions MSBV If 200 x 200mm hole pattern is shifted high on the screen, attach the MSBV bracket (A) vertically with four M5 or M6 screws (Bag B or Bag C). (See Figure 8) "X" Attach MSBV using fasteners at...
- Page 8 F 877.894.6918 / 952.894.6918 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 Chief, a products division of F +31 (0) 495 580 845 Milestone AV Technologies Asia Pacific A Office No. 918 on 9/F, Shatin Galleria...
