This manual serves the following
ComNet Model Numbers:
FVT1001M1
FVR1001M1
FVT1001S1
FVR1001S1
INSTALLATION AND OPERATION MANUAL
FVT/FVR1001(M,S)1
10-bIT dIGITAl VIdEo
The FVT/FVR1001 series video transmitter/receiver supports the transmission of
short-haul quality 10-bit digital video over one multimode or single mode optical
fiber. This module is universally compatible with major CCTV camera manufacturers.
Plug-and-play design ensures ease of installation and no electrical or optical
adjustments are ever required.
bi-color (Red/Green) lEd indicators are provided for rapidly ascertaining equipment
operating status. Figure 4 on Page 3 describes the indicators for each light on the unit.
The FVT/FVR1001 is interchangeable between stand-alone or card mount configurations, or
may be dIN-rail mounted by the addition of ComNet model dINbKT1 adaptor plate.
See Figure A on Page 4 for mounting instructions.
INS_FVT/FVR1001_REV–
01/13/12
PAGE 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comnet FVT1001 Series
Summary of Contents for Comnet FVT1001 Series
- Page 1 Figure 4 on Page 3 describes the indicators for each light on the unit. The FVT/FVR1001 is interchangeable between stand-alone or card mount configurations, or may be dIN-rail mounted by the addition of ComNet model dINbKT1 adaptor plate. See Figure A on Page 4 for mounting instructions.
- Page 2 INSTALLATION AND OPERATION MANUAL FVT/FVR1001(M,S)1 FIGURE 1 – FVT/FVR1001 MULTIMODE OR SINGLE MODE OPTICAL FIBER BLACK BLACK WITH WHITE STRIPE Power Supply: Surface Mount: 8-15 VDC @ 2W Rack Mount: From Rack NOTE: Remove Electrical Connector for Rack Mount Units FIGURE 2 –...
- Page 3 INSTALLATION AND OPERATION MANUAL FVT/FVR1001(M,S)1 FIGURE 4 – LED INDICATORS LINK VIDeo poWer GreeN Communication link An active video signal Unit powered up has been established is present on the bNC over optical fiber connector. Communication – – link has not been established.
- Page 4 8 TurNberry parK roaD | GILDerSome | morLey | LeeDS, uK LS27 7Le T: +44 (0)113 307 6400 | F: +44 (0)113 253 7462 | INFo-europe@comNeT.NeT INS_FVT/FVR1001_REV– 01/13/12 © 2012 Communications Networks Corporation. All Rights Reserved. “ComNet” and the “ComNet logo” are registered trademarks of Communication Networks, llC. PAGE 4...
