INSTALLATION AND OPERATION MANUAL
CLFE1EOC(E,P)/M Series
MINI ETHERNET-OVER-COPPER EXTENDER REMOTE UNITS
POWERED BY EXTERNAL OR POE SOURCE
The ComNet™ CopperLine® Ethernet-over-coax minis are an ultra-small form factor
addition to the ComNet Copperline product family. These miniature remote units
provide 10/100 Mbps Ethernet data with or without Pass-through PoE power over
extended distance coaxial cable. Available in both standard and PoE applications,
the mini CopperLine units are automatically configured as remote units.
Bi-color (Red/Green) LED indicators are provided for rapidly ascertaining equipment
operating status. Table 3 on Page 4 describes the LED indicators for each light on
the unit.
The mini CopperLine units are stand-alone with a small footprint for use where
space is extremely limited. They may optionally be DIN-rail mounted by the
addition of ComNet model DINBKT4 adaptor. See Figure A on Page 5 for mounting
instructions.
INS_CLFE1EOCX/M-REV- 12/23/14 PAGE 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COPPERLINE CLFE1EOCE/M and is the answer not in the manual?

Questions and answers

Summary of Contents for Comnet COPPERLINE CLFE1EOCE/M

  • Page 1 The mini CopperLine units are stand-alone with a small footprint for use where space is extremely limited. They may optionally be DIN-rail mounted by the addition of ComNet model DINBKT4 adaptor. See Figure A on Page 5 for mounting instructions.
  • Page 2 INSTALLATION AND OPERATION MANUAL CLFE1EOC(E,P)/M SERIES FIGURE 1 – CLFE1EOCE/M SINGLE CHANNEL COAX REMOTE EXTERNALLY POWERED UNIT ETHERNET Black w/ White Stripe (AC or DC–) EXT DISTANCE Black (AC or DC+) Power: 9 to 36 VDC OR 24 VAC Power Consumption: 1.5 W FRONT REAR 10/100 data rate DIP switch...
  • Page 3: Application Diagrams

    IMPORTANT NOTE. PLEASE READ. The applications are shown as general representations only and are not intended to show detailed network topologies. Your actual network will differ, requiring changes or perhaps additional network equipment to accommodate the systems as illustrated. Please contact ComNet’s Design Center to discuss your specific requirements. APPLICATION NOTES Mixed PoE and Non-PoE systems can be implemented.
  • Page 4: Installation Instructions

    Provided from Head End CopperLine unit. CLFE1EOCP/M No external power required Contact ComNet pre-sales support, or refer to the appropriate installation and operation manual when configuring and specifying power for a deployment. † 7 - VERIFY FUNCTIONALITY See LED table below and Troubleshooting Guide if corrective action is needed. See figures beginning on page 6 for LED configurations for each model.
  • Page 5: Communication Networks

    LEEDS, UK LS27 7LE T: +44 (0)113 307 6400 F: +44 (0)113 253 7462 INFO-EUROPE@COMNET.NET © 2015 Communication Networks. All Rights Reserved. “ComNet,” the “ComNet Logo,” “CopperLine,” and the “CopperLine Logo” are registered trademarks of Communication Networks. INS_CLFE1EOCX/M-REV- 12/23/14 PAGE 5...
