Table of Contents

This manual serves the following
ComNet Model Numbers:
CLRFE1EOCE/M
CLRFE1EOCP/M
TECH SUPPORT: 1.888.678.9427
INSTALLATION AND OPERATION MANUAL
CLRFE1EOC(E,P)/M Series
MINI ETHERNET-OVER-COPPER EXTENDER REMOTE UNITS
POWERED BY EXTERNAL OR POE SOURCE
The ComNet CopperLine® Ethernet-over-coax minis are an ultra-small form factor
addition to the ComNet Copperline product family. These miniature remote units
provide 10/100 Mbps Ethernet data with or without Pass-through PoE power over
extended distance coaxial cable. Available in both standard and PoE applications,
the mini CopperLine units are automatically configured as remote units.
Bi-color (Red/Green) LED indicators are provided for rapidly ascertaining equipment
operating status. Table 3 on Page 4 describes the LED indicators for each light on
the unit.
The mini CopperLine units are stand-alone with a small footprint for use where
space is extremely limited. They may optionally be DIN-rail mounted by the
addition of ComNet model DINBKT4 adaptor. See Figure A on Page 5 for mounting
instructions.
INS_CLRFE1EOCX/M-REV- 12/23/14 PAGE 1
