Important Safety Warning:
Read and keep these directions
heed all warnings
Follow all instructions
do not use this apparatus near water
Clean only with a dry cloth
Install in accordance with the manufacturer's
instructions
this installation should be made by a qualified
service person and should conform to all local codes
See further safety instructions on Page 8
INSTALLATION AND OPERATION MANUAL
CLFE(X)COAX
EthERNEt-OVER-COAX EXtENdER
wIth PASS-thROuGh POE
the ComNet
CopperLine CLFE(X)COAX Ethernet over COAX line consists of four
™
models that support 100Mbps Ethernet as well as Pass-through Power over Ethernet
(PoE) over standard 75Ω coaxial cable. these models support transmission distances
of up to 5,000 feet (1524m) at 10 Mbps, or 1800 feet (548m) at 100 Mbps. the
CLFE1COAX, the CLFE4COAX, CLFE8COAX and the CLFE16COAX transport, one, four,
eight or sixteen channels respectively. the IEEE 802.3-compliant extenders also
meets the requirements for IEEE 802.3af/at PoE power, passing through up to 30
watts of power per port to the powered device (Pd). the CLFE(X)COAX series may also
be used interchangeably with other CopperLine Ethernet-over-Coax extenders.
Environmentally hardened to the requirements of NEMA tS-1/ tS-2 for most out-of-plant
applications, and true plug-and-play design ensures ease of installation and operation.
LEd indicators are provided for rapidly ascertaining the operating status of the
device. See Figures 7 and 8 on Page 7 for LEd explanations.
Packaged in a rugged aluminum housing, these units are designed for desktop or stand-
alone mounting. the CLFE8COAX and CLFE16COAX are offered in EIA 19" 1u high rack for
easy installation. See Figures A through C on Page 8 for mounting instructions.
See Figures 1 – 8 for complete installation details.
INS_CLFEXCOAX_REV–
09/28/11
PAGE 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CLFECOAX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Comnet CLFECOAX

Summary of Contents for Comnet CLFECOAX

  • Page 1 INSTALLATION AND OPERATION MANUAL CLFE(X)COAX EthERNEt-OVER-COAX EXtENdER wIth PASS-thROuGh POE the ComNet CopperLine CLFE(X)COAX Ethernet over COAX line consists of four ™ Important Safety Warning: models that support 100Mbps Ethernet as well as Pass-through Power over Ethernet Read and keep these directions (PoE) over standard 75Ω...
  • Page 2 INSTALLATION AND OPERATION MANUAL CLFE(X)COAX FIGURE 1 – CLFE1COAX CAT5/6 COAX (75Ω) – POwer SuPPly COnneCTiOn via external power adaptor Optional, if there is no power supply connected to the unit it will try to detect PoE. FIGURE 2 – CLFE1COAX leFT PAnel riGHT PAnel Note: Center...
  • Page 3 PAss-ThROUGh PoE OPERATIOns FOR ThE CLFE1COAX Comnet’s Copperline ClFe1COAX extended distance iP data and Poe maintains the safety standards for communications found within the 802.3af and 802.3at Poe standards. This is for the protection of products operating in the extended distance transmission chain.
  • Page 4 INSTALLATION AND OPERATION MANUAL CLFE(X)COAX FIGURE 4 – CLFE8COAX 12V Power Supply COAX (75Ω) COAX (75Ω) CAT5/6 CAT5/6 Ground Screw* * wArninG: A ground connection is required for the surge protection to work. Failure to ground properly voids the warranty and may cause damage. FIGURE 5 –...
  • Page 5 INSTALLATION AND OPERATION MANUAL CLFE(X)COAX FIGURE 6 – POssIBLE EThERnET COnFIGURATIOns Multiple Configurations are possible. Consult ComNet Design Center. Single Port CopperLine over Coax ≤5,000ft ≤328ft (1524m) Coax (100m) Cat-5 PoE Switch CLFE1COAX CLFE1COAX PoE Camera CNGE2FE24MSPOE Multi Port CopperLine over Coax ≤5,000ft...
  • Page 6 INSTALLATION AND OPERATION MANUAL CLFE(X)COAX IP CAmERA-End EThERnET swITCh/nVR-End InsTALLATIOn (CLFE1COAX) InsTALLATIOn (CLFE(X)COAX) Set the Remote/Local dip switch to “Remote” Set the Remote/Local dip switch to “Local” mode. mode. Set the S1 dip switch to the appropriate rate Set the S1 10/100Baset dip switch to the S1 S2 S1 S2 based on the maximum data rate.
  • Page 7 INSTALLATION AND OPERATION MANUAL CLFE(X)COAX FIGURE 7 – LEd IndICATORs POWER TRAFFIC (Extended) 10/100BaseT GREEN – – Connection is OK, 10Baset mode YELLOW – – – Power is on Flashing, traffic present Connection is OK, 100Baset mode Power is off No traffic –...

  • Page 8: Installation Considerations

    3.73" (9.5cm) FIGURE B Dimensions are for the CLFE4COAX standalone ComNet module 1.6" (4cm) 3.3" (8.4cm) 3.6" (9.2cm) FIGURE C Dimensions are for the CLFE8COAX and CLFE16COAX ComNet modules 3.25" (8.25cm) 17" (43.2cm) 1.75" (4.45cm) INS_CLFEXCOAX_REV– 09/28/11 TECh SUPPORT: 1.888.678.9427...

  • Page 9: Important Safeguards

    8 TURNBERRY PARk ROAD | GILDERSOME | MORLEY | LEEDS, Uk LS27 7LE T: +44 (0)113 307 6400 | F: +44 (0)113 253 7462 | INFO-EUROPE@COMNET.NET INS_CLFEXCOAX_REV– 09/28/11 © 2011 Communications Networks Corporation. All Rights Reserved. “ComNet” and the “ComNet Logo” are registered trademarks of Communication Networks, LLC. PAGE 9...
