B-Tech Mountlogic BT7581 Installation Manual & Parts List

Flat screen ceiling mount for small screens
Hide thumbs

Advertisement

Quick Links

Download this manual
BT7581
FLAT SCREEN CEILING MOUNT
FOR SMALL SCREENS
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Mount
PLEASE KEEP THIS FOR FUTURE REFERENCE
Installation Safety Notes.......................................................................................................................2
Parts List..............................................................................................................................................4
Installation Instructions.........................................................................................................................6
Product Dimensions............................................................................................................................11
B-Tech Contact Details.......................................................................................................................12
INSTALLATION TOOLS REQUIRED
Crosshead
screwdriver
B-TECH AUDIO VIDEO MOUNTS
FEATURES
● Designed for flat screen up to 23" (58cm) / 10kg (22lbs)
● Fits screens with VESA mounting patterns:
50 x 50mm, 75 x 75mm and 100 x 100mm
● Fixed ceiling drop of 205mm (8")
● Features +/- 90° tilt and 360° swivel
● Post installation screen levelling
● Cover plate included for smart installation
● Simple installation
● All mounting hardware included
CONTENTS
8mm (1/3") masonry bit
Drill
or 3mm (1/8") wood bit
www.btechavmounts.com
Pencil

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mountlogic BT7581 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for B-Tech Mountlogic BT7581

Summary of Contents for B-Tech Mountlogic BT7581

  • Page 1: Table Of Contents

    ● Simple installation ● All mounting hardware included CONTENTS Installation Safety Notes........................2 Parts List..............................4 Installation Instructions.........................6 Product Dimensions..........................11 B-Tech Contact Details........................12 INSTALLATION TOOLS REQUIRED Crosshead 8mm (1/3") masonry bit Pencil Drill screwdriver or 3mm (1/8") wood bit B-TECH AUDIO VIDEO MOUNTS www.btechavmounts.com...

  • Page 2: Installation Safety Notes

    Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. In such cases, all guarantees will expire.
  • Page 3 Niniejszy produkt musi być zamontowany na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia. A B-Tech International Ltd. recomenda que a instalação deste produto seja efectuada por um instalador de AV profissional ou outra pessoa devidamente habilitada. A B-Tech International Ltd. e os seus distribuidores e concessionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta.

  • Page 4: Parts List

    BT7581 PARTS LIST Supplied pre-assembled Suitable for loads up to 10kg (22lbs)
  • Page 5 FLAT SCREEN INTERFACE KIT PART NAME (FOR ATTACHING MOUNT TO CEILING PLATE BACK OF FLAT SCREEN) COVER PLATE M8 NUT M8 SPRING WASHER SPACER LONG EXTENSION ROD BALL JOINT M6 x 6mm GRUB SCREW M6 x 10mm GRUB SCREW M8 FEMALE ADAPTOR INTERFACE PLATE M8 x 20mm HEX SCREW SECURITY CABLE...

  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS Remove the cover plates, then fix the ceiling plate to the ceiling. ONLY USE PART A3 WHEN FIXING TO CONCRETE CEILINGS...
  • Page 7 Re-attach the cover plates.
  • Page 8 Attach interface plate to the flat screen using 3 interface screws (parts A). FLAT SCREEN Connect the adaptor to the ball joint and secure using parts 9. FLAT SCREEN...
  • Page 9 Place cable loop over vacant screw hole, secure in place using parts B and C. FLAT SCREEN FLAT SCREEN...
  • Page 10 Adjusting the screen. 90° FLAT SCREEN 360°...

  • Page 11: Product Dimensions

    3.9" 88mm 75mm 3.5" 3" 14.5mm 50mm 0.6" 2" 45mm 1.8" 59mm 2.3" 74mm 115mm 2.9" 4.5" THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.

  • Page 12: B-Tech Contact Details

    ©2010 Bennett Technologies Limited. All rights reserved. B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech, Better By Design and Mountlogic are registered trademarks of Bennett Technologies Limited. All other brands and product names are trademarks of their respective owners.
