BT8341
UNIVERSAL POP-OUT VIDEOWALL
MOUNTING SYSTEM
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Videowall Mounting System
PLEASE KEEP THIS FOR FUTURE REFERENCE
Configurations may differ from the ones
shown in this installation manual
Installation Safety Notes...................................................................................................... ...............2
Parts List.............................................................................................................................................4
Installation Notes............................................................................................................... .................6
Installation Instructions........................................................................................................................8
Product Dimensions..........................................................................................................................18
B-Tech Contact Details.....................................................................................................................20
INSTALLATION TOOLS REQUIRED
Crosshead
screwdriver
CONTENTS
10mm (7/16")
Drill
masonry bit or
6mm (1/4") wood bit
B-TECH AV MOUNTS
www.btechavmounts.com
FEATURES
• Modular mounting system designed for screens
up to 50kg (110lbs)
• Suitable for landscape or portrait mounting (minimum
screen size is 39" when used in landscape orientation)
• P
ush to open / push to close system provides quick and
easy service access
• Depth to wall: 104mm
•
Tool-less micro-adjustment including lateral
adjustment for seamless alignment of the screen display
• Height adjustment +/- 25mm
• Depth adjustment +/- 10mm
• Safety screws help prevent unauthorised removal of screens
•
Includes an optional pop-out prevention mechansim
•
All mounting hardware included
PER SCREEN
Pencil
50kg
Stud finder
Level
(optional)
TM
