- Page 1 VA6111AF User information Dishwasher...
- Page 2 Dear customer, Please read this User Information carefully and keep it to refer to at a later date. Pass this User Information on to any subsequent owner of the appli- ance. The following symbols are used in the text: Safety instructions Warning: Notes that concern your personal safety.
-
Page 3: Table Of Contents
Contents Operating Instructions ........Safety . -
Page 4: Operating Instructions
Operating Instructions 1 Safety Prior to using for the first time • Follow the ”Instructions for installation and connection”. Correct use • The dishwasher is only intended for washing domestic dishes. • Additions or modifications to the dishwasher are not permitted. •... -
Page 5: Diagram Of Appliance
Diagram of appliance Top Spray Nozzle Upper basket spray arm and floor spray arm Water hardness dial Dispenser for special salt Dispenser for detergent Dispenser for rinse aid Rating plate Filters Control panel ON/OFF button The ON/OFF button is used to turn the dishwasher on and off. - Page 6 Programme buttons Multi-display Control Function buttons delay timer indicators The Programme buttons are used to select the desired dishwashing cy- cle. Function buttons: In addition to the pre-set dishwashing cycle, the following functions can also be set using these buttons: Function button 1 Sets the water softener Activates/deactivates rinse aid inflow when...
-
Page 7: Prior To Using For The First Time
The control indicators have the following meanings: Refill with special salt Refill with rinse aid 3 IN 1 3 in 1 function activated 1) These control indicators are never illuminated while a dishwashing cycle is running. Prior to using for the first time If you wish to use 3 in 1 detergent: –... - Page 8 Setting electronically: 1. Press the ON/OFF button. If indicators for the programme buttons are lit, a dishwashing cycle is activated. The cycle must be deactivated: Press function buttons 2 and 3 simultaneously for approx. 2 seconds. All additional wash programme button indicators will go out. 2.
-
Page 9: Adding Special Salt
Adding special salt To decalcify the water softener, it must be filled up with special salt. Use only special salt suitable for domestic dishwashers. If you do not use 3 in1 detergent, fill up with special salt: – Before using the dishwasher for the first time. –... -
Page 10: Filling Up With Rinse Aid
Filling up with rinse aid With rinse aid the rinsing water drains away better and so you get smear-free, gleaming dishes and clear glasses. If you do not use 3in1 detergent, fill up with rinse aid: – Before using the dishwasher for the first time. –... - Page 11 Setting the amount of rinse aid required Only change the amount dispensed, if smears, milky spots (reduce the amount) or dried on water spots (increase the amount) can be seen on glasses and dishes. (See section “If dishwashing results are not satisfac- tory”.) The dosage can be set from 1-6.
-
Page 12: In Daily Use
In daily use Loading cutlery and dishes Sponges, cleaning cloths and any other objects that can absorb water must not be washed in the dishwasher. Plastic and Teflon-coated dishes and pans tend to retain water droplets. These dishes and pans therefore do not dry as well as those made of china and stainless steel. - Page 13 Loading cutlery Warning: Sharp knives and other items of cutlery with sharp edges must be laid in the cutlery rack or in the upper basket to avoid the risk of injury. To ensure that all items of cutlery in the cutlery basket can be reached by the water, you should: 1.Place the grid insert on the cut- 2.Place forks and spoons in the...
- Page 14 To make it easier to load larger dish- es, the two plate rests on the right in the lower basket can be folded down. Cups, Glasses, Coffee Service Load smaller, fragile crockery and long, sharp cutlery in the upper bas- ket.
-
Page 15: Adjusting The Height Of The Upper Basket
Adjusting the height of the upper basket Maximum height of dishes in the Upper basket Lower basket with upper basket raised 22 cm 30 cm with upper basket lowered 24 cm 29 cm The height of the baskets can also be adjusted when they are loaded. Depending on the model, your appliance is provided with one of the following types of upper basket: Type 1... -
Page 16: Adding Detergent
Adding detergent Detergents remove the dirt from dishes and cutlery. The detergent must be added before the cycle starts. Only use detergent intended for do- mestic dishwashers. The detergent compartment is lo- cated on the inside of the door. 1. If the lid is closed: Press the release button. -
Page 17: Using 3In1 Detergents
Concentrated detergents Today’s detergents for dishwashers are almost exclusively low-alkaline concentrated detergents with natural enzymes in tablet or powder form. Using 50°C dishwashing cycles in conjunction with these concentrated detergents reduces pollution and is good for your dishes, as these dish- washing cycles are specially matched to the dirt-dissolving properties of the enzymes in concentrated detergents. - Page 18 3. Press function button 4. The 3 IN 1 indicator indicates the current setting: 3 IN 1 Indicator is lit 3 in 1 function activated 3 in 1 function not activated 3 IN 1 Indicator is not lit (factory setting). 4.
-
Page 19: Selecting The Dishwashing Cycle (Cycle Table)
Selecting the dishwashing cycle (Cycle Table) Programme Consumption sequence values Dishwashing- Suitable Type of cycle for: soiling heavily soiled, Dinner service dried-on food re- • • • • and cookware mains, in particular protein and starch normally soiled, Dinner service dried-on food re- •... - Page 20 Selecting a programme When your dishes look like this, select: an intensive programme. a normal or energy-saving pro- gramme.
-
Page 21: Starting A Dishwashing Cycle
Starting a dishwashing cycle 1. Check that the spray arms can turn freely. 2. Turn the water tap on fully. 3. Close the door. 4. Press the ON/OFF button. 5. Select the desired cycle. The programme indicator comes on. The remaining time expected for the cycle will be shown in the multi-display. -
Page 22: Setting The Delay Timer
Setting the Delay Timer With the delay timer you can delay the start of a dishwashing cycle for between 1 and 19 hours. 1. Press the Delay Timer button repeatedly until the multi-display shows the desired time delay, for example 12h, if the cycle is to start in 12 hours. -
Page 23: Care And Cleaning
Removing the dishes It is normal for the inner door and the dispensers to be damp. • Empty the lower basket first, then the upper basket. This way you avoid dripping water from the upper basket onto dishes in the lower basket. - Page 24 5. Remove the flat filter (3) from the base of the washing compartment and clean both surfaces thoroughly. 6. Re-insert the flat filter. 7. Place the fine filter in the micro-fil- ter and fit the two together. 8. Insert the filter system in place and lock it by turning the handle clock- wise as far as it will go.
- Page 25 3. Place cleaned upper basket spray arm back in position against the connect- ing piece: press the two together firmly, until you feel them snap into place. Bottom spray arm 1. To remove bottom spray arm, pull it upwards out of its catch. 2.
-
Page 26: What To Do If
What to do if... Remedying small malfunctions If one of the following fault codes is displayed in the multi-display dur- ing operation: – Fault codeÅ 10 (Problems with water inlet), – Fault codeÅ 20 (Problems with water drainage), please have a look at the following table. When the fault is remedied, press the button for the cycle that has started. - Page 27 Malfunction Possible cause Remedy First shut off the water tap, Å 30 Fault code is dis- The anti-flood system has then switch off the appli- played in the multi-dis- been triggered. ance and contact the Cus- play. tomer Care Department. The mains plug is not Plug in mains plug.
-
Page 28: If The Dishwashing Results Are Not Satisfactory
If the dishwashing results are not satisfactory The dishes are still dirty. • The wrong dishwashing cycle was selected. • The dishes were loaded is such a way that the dishwashing water did not reach all items. The baskets for the dishes must not be overload- •... -
Page 29: Disposal
Disposal Packaging material The packaging materials are environmentally friendly and can be recy- cled. The plastic components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materials in the appropriate container at the community waste disposal facilities. Old appliance The symbol on the product or on its packaging indicates that this... -
Page 30: Technical Data
Technical data Capacity: 12 place settings including serving dishes Permitted water pres- 1-10 bar (=10-100 N/cm = 0.1-1.0 MPa) sure: 230 V, 10 A, also see the rating plate on the right-hand side Electrical connection: of the dishwasher’s interior door Total output 2250 W Dishwasher: Free-standing appliances... -
Page 31: Notes For Test Institutes
Notes for Test Institutes Testing in accordance with EN 60704 must be carried out with the appliance fully loaded and using the test cycle (see “Cycle Table”). Tests in accordance with EN 50242 must be carried out when the salt dispenser in the water softener and the rinse aid dispenser have been filled with salt and rinse aid respectively, and using the test cycle (see “Cycle Table”). - Page 32 Lower basket with cutlery basket Cutlery basket *) If there are cup racks in place on the lefthand side or if beer glass holders are in place, remove them.
-
Page 33: Installation And Connection Instructions
Installation and connection instructions 1 Safety information for the installation • Only transport the dishwasher in an upright position, otherwise salt water may run out. • Before using the dishwasher for the first time, check for any damage caused in transport. Do not under any circumstances connect an ap- pliance that is damaged. -
Page 34: Installing The Dishwasher
Installing the dishwasher • The dishwasher must be installed on a firm floor and adjusted to en- sure that it is stable and level in all directions. • To compensate for unevenness in the floor and to match the height of the appliance to that of sur- rounding units, extend the thread- ed feet using a screwdriver. -
Page 35: Connecting The Dishwasher
Connecting the dishwasher Connecting to the water supply • The dishwasher can be connected to cold and hot water supplies up to max. 60°C. • The dishwasher must not be connected to open hot water appliances or instantaneous water heaters. Permitted water pressure Lowest permitted water pressure: Consult your plumber if the water pres-... - Page 36 Water drainage Drain hose The drain hose must not be kinked, crushed or entangled. • Connecting the drain hose: maximum permitted height above the bottom edge of the appliance: 60 cm. Extension hoses • Extension hoses are available from your dealer or from our Customer Care Department.
- Page 37 Electrical connection Details about the voltage, type of supply and the fuses required are to be found on the rating plate. The rating plate is located on the right- hand inner edge of the dishwasher door. To isolate the dishwasher from the mains, pull out the mains plug. Important: –...
-
Page 39: Service
