Features - Transition Networks Milan MIL-RC6113SX-V2 User Manual

Features

Standard
LED Indicators
Connector
Fiber
parameters
Link Lose
Forward
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BaseT,
IEEE 802.3z 1000BaseSX/LX standards
IEEE 802.3x Flow Control and Back pressure
Power (Green)
UTP SPD: 1000Mbps /100Mbps
Lnk/Act: UTP /FIBER
FDX: UTP: Full-Duplex mode / Half-Duplex or Link down
FIBER: Full-Duplex mode / Link down
Fiber: Duplex SC/MINI GBIC 3.3V/ WDM
RJ-45 Socket: CAT-5e (10/100/1000Mbps) Twisted Pair
cable Auto MDI/MDI-X and Auto-Negotiation Function
Support
Fiber Core: Multi-Mode (62.5/125um, 50/125um)
Single-Mode (9/125um)
Wavelength: 850nm(Multi-mode),
1310nm(Single-mode)/1310nm(WDM, TX),
1550nm(WDM, RX)
Fiber Distance: 550M (Multi-Mode Fiber)
10 KM (Single-Mode Fiber)
Copper Fiber: If copper port link down, then media
converter will forced fiber to link down.
Fiber Copper: If Fiber port link down, the media converter
3
