H8SME-F SERVERBOARD USER'S MANUAL
2-10 Onboard Indicators
Dedicated IPMI LAN LEDs
A dedicated IPMI LAN is also included
on the H8SME-F serverboards. The
amber LED on the right indicates
activity, while the green LED on
the left indicates the speed of the
connection. See the table at right for
more information.
IPMI Heartbeat LED
An IPMI Heartbeat LED is located at
LED3. When LED3 blinks, the IPMI
functions properly. Refer to the table
on the right for details.
Overheat(OH)/Fan Fail/PWR Fail
LED
A Red Overheat/Fan Fail/PWR Fail
LED is located at LED2. See the table
at right for more information.
2-11 SATA Drive Connections
SATA Ports
There are no jumpers to configure
the SATA ports, which are designated
SATA0 through SATA3. See the table
on the right for pin defi nitions.
IPMI LAN Link LED
(Left) & Activity LED (Right)
Color
Green:
Solid
Amber
Blinking
IPMI Heartbeat (LED3)
LED Settings
Color
Status
Green
Blinking
Off
Off
Overheat(OH)/Fan Fail/PWR Fail
LED (LED2)
LED Settings
Color
Status
Off
Off
Red
On
Red
Flashing
Flashing
Pin Defi nitions
(SATA0-SATA3)
Pin# Defi nition
1
2
3
4
5
6
7
2-18
Status
Defi nition
Link
100 Mb/s
(Left)
Activity
Active
(Right)
Defi nition
IPMI is ready for use
Not functioning
normally
Defi nition
Normal
Overheat
Fan Fail
SATA Ports
Ground
TXP
TXN
Ground
RXN
RXP
Ground
