- Page 1 MANUAL ENGLISH SCS-230 Ordercode: D6612 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
SCS-230 Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 Overview ..................................5 Installation ................................... 6 Set Up and Operation ............................... 6 100V Mode .................................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: DAP Audio SCS-230 • 2 mounting brackets •... -
Page 4: Operating Determinations
Any other operation may lead to dangers like short-circuit, burns, electric shock, etc. You endanger your own safety and the safety of others! Improper installation can cause serious injuries and damage of property ! The SCS-230 can be mounted with the included mounting brackets. Ordercode: D6612... -
Page 5: Return Procedure
SCS-230 Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 6: Description Of The Device
SCS-230 Description of the device Features Power taps: 7,5/15/30W • Line voltage: 100V • Impedance: 6,8 Ω • Speaker size: 4 x 2 + 1 x 1 inch • Frequency response: 180-18 kHz • Sensitivity: 91 dB • Housing: Aluminum •... -
Page 7: Installation
Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Remove the screws from the bottom side of the SCS-230 to gain access to the cables and connectors. Fig. 02 100V Mode 01) Connect the black cable to the common cable. -
Page 8: Product Specification
SCS-230 Product Specification Power taps: 7,5/15/30W Line voltage: 100V Impedance: 6,8 Ω Speaker size: 4 x 2 + 1 x 1 inch Frequency response: 180-18 kHz Sensitivity: 91 dB Housing: Aluminum Color: White IP rating: IP44 Dimensions: 74 x 68 x 400 mm (LxWxH) -
Page 9: Notes
SCS-230 Notes Ordercode: D6612... - Page 10 SCS-230 Ordercode: D6612...
- Page 11 SCS-230 Ordercode: D6612...
- Page 12 ©2015 DAP Audio...
