- Page 1 Soundmate Easy ORDERCODE D3215...
- Page 2 Congratulations! You have bought a great, innovative product from DAP Audio. The DAP Audio Soundmate Easy brings excitement to any venue. Whether you want simple plug-&-play action or a sophisticated show, this product provides the effect you need. You can rely on DAP Audio, for more excellent audio products.
- Page 3 DAP Audio DAP Audio Soundmate Easy Product Guide ™ Warning..…...................………………………………………….. Safety-instructions………………………………………………………………………………………….…. Operating Determinations……………………………………………………………………………………. Description..…................……….………………………………… Features………………………………………………………………………………….………………….…. Overview…………………………………………………………………………………………………..…… Set Up and Operation..............……..………………………………… Product Specifications..............……………….…….……………….…. Set Up Possibilities......…........………..………….…….……………..
-
Page 4: Safety Instructions
WARNING CAUTION! Keep this system away from rain and moisture! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! SAFETY INSTRUCTIONS Every person involved with the installation, operation and maintenance of this system have to: be qualified follow the instructions of this manual CAUTION! Be careful with your operations. -
Page 5: Operating Determinations
For replacement use fuses of same type and rating only. • The user is responsible for correct positioning and operating of the Soundmate Easy. The • manufacturer will not accept liability for damages caused by the misuse or incorrect installation of this device. -
Page 6: Description Of The Device
Description of the device Features Soundmate Easy is a complete sound reinforcement solution consisting of: • 2 mid/high satellite speakers 6,5” 60 Watt / 4 Ohm • 1 active subwoofer 10” 150 watt / 4 Ohm, equipped with amplifier(s) and all the electronics required to run the system. - Page 7 Fig. 2 9) Mic In: Balanced XLR Input jack to connect the microphone. (Pin 1 = Ground; 2= +; 3= - ) 10) Line In: Left/Right: Balanced XLR Input jack to connect the mixer. (Pin 1 = Ground; 2= +; 3= - ) 11) Aux-In: Input phone jack to connect a CD Player or DJ Mixer.
-
Page 8: Set Up And Operation
Set Up and Operation Soundmate Easy is a 2 way active satellitesystem with one 10” 300 watt sub-woofer and two 6,5” 75 Watt mid/high units. The set comes complete with stands and 2 Speakon cables and is ready to use. The amplifier-section is build into the subwoofer and consists of 3 separate power-amplifiers. -
Page 9: Product Specifications
Product Specifications Inputs Line IN L / R Connector XLR plug female Input design electronically balanced & floating Input impedance 48 k Outputs Parallel Out L / R Connector: XLR socket male Satellite Out L / R Connector: Speakon (pin 1+= +; pin 1--= --) Speaker Out: Speakon NL4 Style Connector Active Crossover Crossover freq. - Page 10 Below are a few examples how to set up your Soundmate Easy:...
