A T I
YPICAL NSTALLATION
Anemometer
External
erature
NORTH SIDE OF BUILDING in Northern Hemisphere
SOUTH SIDE OF BUILDING in Southern Hemisphere
The diagram above shows a typical Weather Monitor II installation. The fol-
lowing pages will give you specific instructions for installing your station. To
avoid unnecessary problems, be sure to thoroughly test your system before
installing it.
WARNING: Climbing on your roof can be hazardous. If you are uneasy about installing your
unit, please have a qualified professional complete the installation. Davis specifi-
cally disclaims any liability for injury or loss resulting from the installation or use
of the Weather Monitor II.
Page 4
Temp-
Sensor
Rain Collector
(optional)
WEATHER MONITOR II
To WeatherLink
(optional)
RAIN
TEMP
WIND
Junction Box
AC Power
Adapter
Power
Outlet
Junction Box
Cable
Weather Monitor II
