Crestron CT/LC-WPK Installation Manual

Water Resistant Cover Kit for
Series 1000: CT/LC-WPK
The Crestron
cover for a mounted panel. There are four covers per kit. When properly installed the cover
prevents liquids and other air-born materials from settling directly onto the panel, but does not
interfere with regular usage of the unit.
No tools are required to install the CT/LC-WPK cover; a silicone rubber adhesive is provided.
The panel must be properly setup (i.e., cleaned and connected to the network) as outlined in
the Series 1000 Operations & Installation Guide prior to installing the cover. Complete the
steps listed adjacent to the diagram for installation.
MOUNTING
SURFACE
WARNING: Silicone rubber adhesive is an irritant to skin, eyes, and respiratory tract. Skin and eye
protection required. Avoid repeated or prolonged contact. Good ventilation is required.
WARNING: To avoid shock hazard and possible damage to the unit, never install a touchpanel where it
may be exposed to rain or very high humidity. This kit is designed to resist water (eg. protect unit from
wet hands) and in no way provides waterproof protection.
Further Inquiries
If you still have questions after reviewing this sheet, please take advantage of Crestron's
award winning customer service team by calling
1-888-CRESTRON [1-888-273-7876]. For assistance in your local time zone, refer to the Crestron
website (http://www.crestron.com) for a listing of Crestron worldwide offices.
You can also log onto the online help section of the Crestron website to ask questions about
Crestron products. First-time users will need to establish a user account to fully benefit from
all available features.
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576

water resistant cover kit for the Series 1000 touchpanel provides a urethane
CT/LC-WPK
COVER
INSTALLED
SERIES 1000
TOUCHPANEL
GAP
LOCATION
the Crestron corporate headquarters at
Water Resistant Cover Kit for Series 1000: CT/LC-WPK
Specifications subject to change without notice.
1. Remove the backing from
the tape that surrounds
the perimeter of the
cover.
2. Place the cover over the
panel making sure that
the gap in the tape
perimeter is located at
the bottom.
3. Firmly press down the
cover so that it
completely encloses the
touchpanel.
4. Except for the gap at the
bottom, apply a bead of
silicone rubber adhesive
around the outer edge of
the cover (form a seal
with the mounting
surface).
5. Do not use the touch-
panel while the adhesive
cures (typically 24 hours).
DOC. 5932
04.01
