- Page 1 Crestron CEN-IDOC Interface for Apple iPod ® ® Operations Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2006 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Hardware Hookup ... 8 Operation ... 10 Programming Software ... 11 Earliest Version Software Requirements for the PC ... 11 Programming with Crestron SystemBuilder... 11 Programming with SIMPL Windows ... 11 Example Program ... 13 Uploading and Upgrading... 14 Establishing Communication... 14 Programs and Firmware ... -
Page 5: Interface For Apple Ipod: Cen-Idoc • 1
Wheel, iPod mini, iPod Nano, iPod Photo, and iPod Video* • Connects to the iPod’s dock connector with the included 8 foot (2.44 meter), 30 pin cable or the included CEN-IDOC-DS docking station • Charges iPod battery when connected •... -
Page 6: Specifications
Interface for Apple iPod Specifications Specifications for the CEN-IDOC are listed in the following table. CEN-IDOC Specifications 2 Interface for Apple iPod: CEN-IDOC SPECIFICATION Power Requirements Included Power Supply Minimum 2-Series Control System Update File Interface Cable Compatible Docking Station... -
Page 7: Physical Description
Physical Description This section provides information on the connections, controls, and indicators available on your CEN-IDOC. CEN-IDOC Physical View CEN-IDOC Physical View (rear), Shown with Included Interface Cable Operations Guide – DOC. 6404A Interface for Apple iPod Interface for Apple iPod: CEN-IDOC • 3... - Page 8 6.41 in (16.27 cm) 7.30 in (18.54 cm) CONNECTORS, CONTROLS, & INDICATORS SETUP One recessed miniature pushbutton used to set unit’s IP ID in conjunction with Crestron Toolbox. Crestron CEN-IDOC 1.75 in (4.46 cm) DESCRIPTION Operations Guide – DOC. 6404A...
- Page 9 Pin 5: N/A Pin 6: RIGHT (-) Pin 7: N/A Pin 8: N/A Pin 1: CTS Pin 2: GND Pin 3: RXD Pin 4: TXD Pin 5: RTS Pin 6: N/C (Not connected) Interface for Apple iPod: CEN-IDOC • 5...
-
Page 10: Industry Compliance
Interface for Apple iPod Industry Compliance As of the date of manufacture, the CEN-IDOC has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. NOTE: This device complies with part 15 of the FCC rules. Operation is subject to... -
Page 11: Setup
The IP IDs of multiple CEN-IDOC devices in the same system must be unique. When setting the IP ID, consider the following: Installation The CEN-IDOC can be mounted in a rack or to any surface using the integral mounting flanges. Mounting hardware is not provided. Operations Guide – DOC. 6404A ... -
Page 12: Hardware Hookup
8 Interface for Apple iPod: CEN-IDOC • Use Crestron power supplies for Crestron equipment. • The CEN-IDOC-DS is the only docking station that can be used with the CEN-IDOC. • The included 8 foot (2.44 meter) cable cannot be extended. - Page 13 Crestron CEN-IDOC Plug & Play Use with Adagio If the CEN-IDOC is used with an Adagio Audio Entertainment System (AES) or Systems Adagio Audio Distribution System (AADS) operating with the out-of-the-box functionality, the LAN ports of the CEN-IDOC and the AES/AADS must be connected to the same DHCP router.
-
Page 14: Operation
CEN-IDOC-DS guide (Doc. 6454) which is available for download from the Crestron website. An iPod connected to a CEN-IDOC can be easily controlled from the front panel of an Adagio Entertainment System (AES) or Adagio Audio Distribution System (AADS). -
Page 15: Programming Software
Have a question or comment about Crestron software? Answers to frequently asked questions (FAQs) can be viewed in the Online Help section of the Crestron website. To post a question or view questions you have submitted to Crestron’s True Blue Support, log in at http://support.crestron.com. - Page 16 The symbol can be viewed by double 12 Interface for Apple iPod: CEN-IDOC • To incorporate the CEN-IDOC into the system, drag the CEN-IDOC from the Ethernet Control Modules | Ethernet Audio Modules folder of the Device Library and drop it in the System Views.
-
Page 17: Example Program
Detail View. A description for each signal in the symbol is described in the SIMPL Windows help file (F1). Example Program An example program for the CEN-IDOC is available from the Crestron website (http://www.crestron.com/exampleprograms). Operations Guide – DOC. 6404A... -
Page 18: Uploading And Upgrading
• Establish direct serial communication between CEN-IDOC and PC. • Enter the IP address, IP mask, and default router of the CEN-IDOC via the Crestron Toolbox (Functions | Ethernet Addressing); otherwise enable DHCP. •... -
Page 19: Programs And Firmware
A defined IP table can be saved to a file or sent to the device. • Edit the control system ‘s IP table to include an entry for the CEN-IDOC. The entry should list the CEN-IDOC’s IP ID (specified on the CEN-IDOC’s IP table) and the internal gateway IP address 127.0.0.1. -
Page 20: Problem Solving
Interface for Apple iPod Problem Solving Troubleshooting The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. CEN-IDOC Troubleshooting 16 Interface for Apple iPod: CEN-IDOC TROUBLE POSSIBLE CAUSE(S) -
Page 21: Reference Documents
For assistance in your local time zone, refer to the Crestron website (http://www.crestron.com/) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 22: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 23 ® ® Crestron CEN-IDOC Interface for Apple iPod This page is intentionally left blank. Interface for Apple iPod: CEN-IDOC • 19 Operations Guide – DOC. 6404A...
- Page 24 Crestron Electronics, Inc. Operations Guide – DOC. 6404A 15 Volvo Drive Rockleigh, NJ 07647 (2013794) Tel: 888.CRESTRON 07.06 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
