Architectural Series Faceplates:
CT/LC-FPAR1000
Description
Architectural Series Faceplates bring a clean, updated look to the CT/LC-1000 series
touchpanels. They feature machined aluminum construction with a stylish shape that is a pleasing
alternative to traditional flat faceplates, and they are available in a variety of finishes including
stainless steel, anodized black, and the standard white and almond. (Refer to the table below.)
Use the following procedure to install the new faceplates. (Refer to the illustration below.)
1. Lift the existing faceplate off
the touchpanel. If necessary,
use a small flat-bladed
screwdriver between the
faceplate and the mounting
surface, using a gentle twist
to free the faceplate.
2. Position the new faceplate
over the touchpanel and
firmly press the faceplate
until it snaps into position.
CAUTION: Do not put pressure on the
touchscreen when removing/installing
faceplates.
5.09 in
(12.93 cm)
Further Inquiries
If you cannot locate specific information or have questions after reviewing this guide, please take
advantage of Crestron's award winning customer service team by calling the Crestron corporate
headquarters at 1-888-CRESTRON [1-888-273-7876]. For assistance in your local time zone,
refer to the Crestron website (www.crestron.com) for a listing of Crestron worldwide offices.
You can also log onto the online help section of the Crestron website to ask questions about
Crestron products. First-time users will need to establish a user account to fully benefit from all
available features.
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576
MODEL NUMBER
CT/LC-FPAR-1000-A
CT/LC-FPAR-1000-A-NB
CT/LC-FPAR-1000-A/BLK
CT/LC-FPAR-1000-A/BLK-NB
CT/LC-FPAR-1000-S/STEEL
CT/LC-FPAR-1000-S/STEEL-NB
CT/LC-FPAR-1000-W
CT/LC-FPAR-1000-W-NB
*Aluminum composition; may not be suitable for
sterile environment.
4.99 in
(12.68 cm)
Front View
W/Buttons
0.29 in
(0.73 cm)
Front View
Side View
W/O Buttons
Architectural Series Faceplates: CT/LC-FPAR1000
Specifications subject to change without notice.
FINISH*
Almond
Almond, W/O Buttons
Anodized Black
Anodized Black, W/O Buttons
Stainless Steel
Stainless Steel, W/O Buttons
White
White, W/O Buttons
Data Sheet – DOC. 6323
03.05
