1-3-1. Port Description

HDMI: Video signal and audio input.
1
EAR: 3.5mm headphones audio output.
2
VGA: Video signal input.
3
LINE IN: Audio signal input when connected VGA.
4
DC 12V: DC 12V power port.
5

1-3-2 . Button Indications

1
Light
Red/Blue light, indicated the working status.
1
Turn on/off the monitor when it powered.
2
By default, the key is the hot key for volume.
+
3
When in the OSD menu, press for up/increase adjustment .
By default, the key is the hot key for volume.
-
4
When in the OSD menu, press for down/decrease adjustment.
Press to display the setting OSD menu.
MENU
5
When in the OSD menu, press to confirm the selection.
AUTO When in the OSD menu, press to exit the OSD menu.
6
2 3 4 5 6
+ -
MENU AUTO
1
2
3
4
5
2019 ELECROW All Rights Reserved.
C
Speaker
