The circuit for measuring the voltage and supply of the meter:
Technical data
installation
rated voltage
minimum measured current
base current
maximum current
voltage measuring range
transformer type
measurement accuracy (IEC62052-11, IEC62053-21)
rated frequency
insulation protection class
own power consumption
indication range
constant
current consumption signalling
read-out signalling
pulse output
type
maximum voltage
maximum current
pulse constant
pulse time
working temperature
terminal
15 neutral N-wire
16 L3 phase
17 L2 phase
18 L1 phase
25 mm² screw terminals
- 6 -
4-wire
3×230/400 V
0.04 A
3×1.5 A
3×5 A
160÷265 V
200/5 A
50 Hz
<10 VA; <2 W
0÷9999999 kWh
300 pulses/kWh
3× red LED
red LED
open collector
27 V DC
27 mA
300 pulses/kWh
35 ms
-25÷55°C
1
II
