Extra Functions
Options for extra functions such as LOGIC CONTROL and ANALOGUE CONTROL/MONITOR,
plus variations on some of the factory default functions, can be set by the user by using the #
extra functions facility. The complete list of functions is accessed by pressing SHIFT, # ; the
required function can be selected directly by entering nn from the keyboard, where nn is the 2-
digit number in the list below, or by scrolling to the appropriate function in the list using the JOG
SET control; the selected function is indicated by the square brackets
list. Press OK to initiate the selected function, following the on-screen prompts where
appropriate. At any time before the OK key is pressed the extra function can be exited without
implementation by pressing ESCAPE or by waiting for the operation to time out.
Selected functions are indicated by a
options within any decade group are mutually exclusive and selecting a function within any group
will automatically deselect any previously selected function in that group, including the factory
default option; for example, if # 26 is selected, 20 -25 and 27 are all deselected.
# Code
10
11
20
21
22
23
24
25
26
27
30
31
40
41
42
50
51
60
61
62
90
91
99
Factory Default Settings
The ex-factory default settings (which will apply at first power-up) are as follows:
Voltage:
Current Limit:
OVP:
OCP:
Output:
# Settings:
Function
Output always off at power-up (factory default)
Output status at power-up same as at last power-down
LOGIC OUT 'closed' for Output ON, 'open' for Output OFF (factory default)
LOGIC OUT 'closed' for Output OFF, 'open' for Output ON
LOGIC OUT 'closed' for any trip
LOGIC OUT 'open' for any trip
LOGIC OUT 'closed' for UNREG
LOGIC OUT 'open' for UNREG
LOGIC OUT 'closed' for CI (current limit)
LOGIC OUT 'open' for CI (current limit)
Buzzer on. A single beep indicates a wrong entry (factory default)
Buzzer off
V CONTROL and I CONTROL both selected (factory default)
V CONTROL only selected
I CONTROL only selected
V CONTROL and I CONTROL scaling 0 to 10 Volts (factory default)
V CONTROL and I CONTROL scaling 0 to 5 Volts
LOGIC IN ignored (factory default)
LOGIC IN active enables output
LOGIC IN active disables output
LCD contrast adjustment
Restores factory defaults, including these # settings
Enter calibration mode. Refer to Service Manual
0.000V
1.00A
65.0V
55.0A
Output off; local sense
10, 20, 30, 40, 50, 60 active
