COMMERCIAL DRYER
MODEL T-30 SWD VENDED
C-SERIES CONTROL, NATURAL GAS/LP HEATED
The dryer must not be stored or installed where it will be exposed to water and/or weather.
WARNING: For your safety the
information in this manual must be
followed to minimize the risk of fire
or explosion or to prevent property
damage, personal injury or loss of
life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Clear the room, building or area of all
occupants.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
– Installation and service must be performed by
a qualified installer, service agency or the
gas supplier.
Post the following "For Your Safety" caution in a
prominent location:
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any other
appliance.
It is important that you read this Manual and retain it
for future reference. For service or replacement parts,
contact
the
distributor
manufacturer.
8514-286-001 REV B PAGE 1
OPERATOR'S MANUAL
INSTALLATION & OPERATION INSTRUCTIONS
in
your
area
or
Dexter Laundry, Inc.
2211 W. Grimes
Fairfield, Iowa 52556
AVERTISSEMENT.
de bien suivre les instructions
données dans cette notice pour
réduire au minimum le risque
d'incendie ou d'explosion ou pour
éviter tout dommage matérial,
toute blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
– QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE
GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones se trouvant
dans le bâtiment où vous vous trouvez.
• Évacuez la pièce, le bâtiment ou la zone.
• Appelez immédiatement votre
fournisseour de gaz depuis un voisin.
Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
– L'installation et l'entretien doivent être assurés par
un installateur ou un service d'entretien qualifié
ou
POUR VOTRE SÉCURITÉ
Ne pas enteposer ni utiliser d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
You, the purchaser, must post in a prominent loca-
tion instructions to be followed in the event the user
smells gas. Consult your local gas supplier for
the
procedure to be followed if the odor of gas is
present.
Assurez-vouz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T-30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dexter Laundry T-30

  • Page 1 COMMERCIAL DRYER MODEL T-30 SWD VENDED C-SERIES CONTROL, NATURAL GAS/LP HEATED OPERATOR’S MANUAL INSTALLATION & OPERATION INSTRUCTIONS The dryer must not be stored or installed where it will be exposed to water and/or weather. WARNING: For your safety the AVERTISSEMENT.
  • Page 2: Warnings About Use And Operation

    TABLE OF CONTENTS Page No. Warnings about use and operation Dryer Specifications Dryer Dimensions Installation Instructions 6-10 Dryer Shutdown Operating Instructions Programming the Dryer Control 12-22 Servicing and Troubleshooting Preventative Maintenance Instructions WARNINGS ABOUT USE AND OPERATION DO NOT MODIFY THIS APPLIANCE. KEEP SHIELDS, GUARDS AND COVERS IN PLACE. These safety devices are provided to protect everyone from injury.
  • Page 3: Specifications

    SPECIFICATIONS 30 lb. Commercial Dryer: T-30 SWD DCS030N_-15EC_X (60Hz), DCS030N_-39AC_X (50Hz) Cabinet Height (As a stand-alone dryer) 38 7/8” 987 mm. (Assumes minimum leveling leg adjustment) Cabinet Height (Combo washer/dryer) 78 3/4” 2000 mm. Cabinet Width 31 1/2” 800 mm.
  • Page 4 Stand-alone Dryer Shipping Weight 420 lbs. 191 kg. Net Weight 380 lbs. 172 kg. Clearance Behind Machines (min.) 18” 457 mm. Combo Stack Washer/Dryer Shipping Weight 1101 lbs. 499 kg. Net Weight 1051 lbs. 477 kg. Clearance Behind Machines (min.) 24”...
  • Page 5: Dryer Dimensions

    DRYER DIMENSIONS 8514-286-001 REV B PAGE 5...
  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS This dryer may have been supplied as part of a washer/dryer stacked appliance. If so, refer to the washer instructions for uncrating and hard mounting the stacked unit to a concrete floor and observe the dryer clearances listed below. STACK WASHER / DRYER INSTALLATION (when necessary): 1.
  • Page 7 FIGURE 2 - VERTICAL CLEARANCE DIMENSIONS 3. MAKE-UP AIR: Adequate make-up air must be supplied to replace air exhausted by dryers on all types of installations. Refer to specifications for the minimum amount of make-up air opening to outside for each dryer. This is a net requirement of effective area.
  • Page 8 on the rear of the unit. It is absolutely necessary that the dryer be grounded to a known ground. Individual circuit breakers for each dryer are required. 5. GAS REQUIREMENTS. The complete gas requirements necessary to operate the dryer satisfactorily are listed on the serial plate located on the back panel of the dryer and in the specifications section of this manual.
  • Page 9 Never install a protective screen over the exhaust outlet. When exhausting a dryer straight up through a roof, the overall length of the duct has the same limits as exhausting through a wall. A rain cap must be placed on top of the exhaust and must be of such a type as to be free from clogging.
  • Page 10: Dryer Shutdown

    iii. Turn on the main electrical power switch. The dryer may be started by following the "Operating Instructions" found later in this manual. Natural gas and LPG fired dryers operate in the same manner. When the gas valve relay contacts are closed (indicating a demand for heat), the solid-state ignition control will automatically supply energy to the redundant gas valve.
  • Page 11 OPERATING INSTRUCTIONS STARTING THE DRYER 1. The display on the dryer control will show the required vend amount when in idle mode. Once the door is opened it will prompt the user to add money. Load clothes into the dryer. Close the door completely. 2.
  • Page 12: Programming The Dryer Control

    PROGRAMMING THE DRYER CONTROL The dryer control can be programmed to prompt the user for alternate vend prices, change dryer cycle times, temperatures and many other options. This can be accomplished in two ways: 1. Manual programming utilizing the “Start”, “High”, “Medium” and “Low” buttons on the dryer. 2.
  • Page 13 Button Name Alternate Function in Programming Mode Becomes the action to accept the displayed option or the “Enter” Start Becomes the action to move UP through displayed options (Press High & hold for accelerated scrolling) Becomes the action to move DOWN through displayed options Medium (Press &...
  • Page 14 The time is based off the Real Time Clock, but potentially shifted by the user’s manual programming changes (Shift Hours option) and/or network time override. As additional error codes occur, the oldest of the five logged codes is cleared from memory. Prices Option: This option allows the user to set values for coin acceptor inputs, vend price &...
  • Page 15 The figure below shows the sub menu options for Prices: 8514-286-001 REV B PAGE 15...
  • Page 16 Cycles Option: This option allows the user to set temperature and cooldown information for the drying cycle. It also allows the user to return the values to factory defaults. 1. “TEMP SETTINGS” allows the user to make adjustments, within a designated range, to the cycling temperature for each of the “Low”, “Medium”...
  • Page 17 The figure below shows the sub menu options for Cycles: 8514-286-001 REV B PAGE 17...
  • Page 18 Temperature Pricing Option: This option allows the user to require additional vend amounts be added based on the drying temperature chosen by the customer. This pricing adder is effective only for the Base Vend Price (it does not affect the Extend Dry Price). It allows a pricing adder separate for “Medium” and “Hot” temperature settings. Example- A store owner has programmed the control for the following: Vend Price $1.00...
  • Page 19 Settings Options: The Settings options allow for the user to make various programming changes to change how the control operation affects the customer. See below for detailed information on each next level option. 1. “Decimal Point”: If the user programs the Decimal Point to “OFF”, control display will not show a decimal point on any vend price values.
  • Page 20 To reset all values in the Settings options to factory default, press “Enter” when the “DEFAULT” prompt is shown. Press “Enter” again when the “RESET” prompt is shown to confirm the action. The figure below shows the sub menu options for Settings: 8514-286-001 REV B PAGE 20...
  • Page 21 Usage Menu: The Usage menu allows for the user to track data about machine usage. See below for detailed information on each sub menu option. 1. “Coin Audit”: The coin audit field shows the accumulation of coin pulses that were sent to the control over each of the left and right coin inputs.
  • Page 22 Control Menu: The Control menu allows for the user to observe important technical information for the control. No changes can be made at this menu. See below for detailed information on each sub menu. 1. “Serial Number”: This is the control serial number. 2.
  • Page 23: Servicing And Troubleshooting

    SERVICING AND TROUBLESHOOTING CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. ATTENTION. Lors des opérations d'entretien des commandes, étiqueter tous les fils avant de les déconnecter. Toute erreur de câblage peut être une source de danger et de panne.
  • Page 24: Preventive Maintenance Instructions

    For service and parts information, contact your local Dexter agent. To find your local Dexter agent, use the Distributor Locator at the website shown below. If a Dexter agent is not available, contact Dexter Laundry, Inc. directly as listed below:...
