Burner and nozzle specifications tables
1 Natural gas G20
Rated heating capacity (kW)
Nozzle diameter (1/100 mm)
Pre-chamber (printed on nozzle)
Reduced flow rate (W)
2 Natural gas G20
Rated heating capacity (kW)
Nozzle diameter (1/100 mm)
Pre-chamber (printed on nozzle)
Reduced flow rate (W)
3 Natural gas G25
Rated heating capacity (kW)
Nozzle diameter (1/100 mm)
Pre-chamber (printed on nozzle)
Reduced flow rate (W)
4 Natural gas G25.1
Rated heating capacity (kW)
Nozzle diameter (1/100 mm)
Pre-chamber (printed on nozzle)
Reduced flow rate (W)
5 Natural gas G25
Rated heating capacity (kW)
Nozzle diameter (1/100 mm)
Pre-chamber (printed on nozzle)
Reduced flow rate (W)
6 Natural gas G27
Rated heating capacity (kW)
Nozzle diameter (1/100 mm)
Pre-chamber (printed on nozzle)
Reduced flow rate (W)
7 Natural gas G2.350
Rated heating capacity (kW)
Nozzle diameter (1/100 mm)
Pre-chamber (printed on nozzle)
Reduced flow rate (W)
Installation
AUX
1.0
72
(X)
400
AUX
1.0
72
(X)
400
AUX
1.0
72
(X)
400
AUX
1.0
77
(F1)
400
AUX
1.0
77
(F1)
400
AUX
1.0
77
(F1)
400
AUX
1.0
94
(Y)
400
SR R UR2 (int+ext)
1.8 2.9
97 120
(Z) (H9)
500 800
SR R UR2 (int+ext)
1.8 2.9
94 113
(Z) (H8)
500 800
SR R UR2 (int+ext)
1.8 2.8
94 120
(Y) (H9)
500 800
SR R UR2 (int+ext)
1.8 2.9
100 134
(Y) (F3)
500 800
SR R UR2 (int+ext)
1.8 2.9
100 134
(Y) (F3)
500 800
SR R UR2 (int+ext)
1.8 2.9
105 138
(Y) (F3)
500 800
SR R UR2 (int+ext)
1.8 2.9
120 165
(Y) (F3)
500 800
4.2
75+135
(H1)+(H3)
1900
4.2
75+127
(H1)+(H3)
1900
4.0
75+135
(H1)+(H3)
1900
4.2
75+138
(H1)+(F3)
1900
4.1
80+145
(Y)+(H3)
1900
4.2
80+148
(H1)+(F3)
1900
4.0
100+190
(0)+(H3)
1900
