TRANSLATION OF THE ORIGINAL INSTRUCTIONS
We advise you to read this manual carefully, which contains all the instructions for
maintaining the appliance's aesthetic and functional qualities.
For further information on the product: www.smeg.com
Contents
60
60
65
65
65
65
65
66
67
67
68
69
70
71
73
74
75
76
83
83
88
92
99
100
101
103
104
105
107
107
112
114
