We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• WARNING: During use the
appliance and its accessible
parts become very hot. Keep
children well away from the
appliance.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
91477A418/A
35
35
39
40
40
40
40
40
41
41
41
41
41
42
42
42
43
43
43
45
45
45
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
eight at a safe distance unless
45
46
47
49
50
51
51
51
51
52
52
54
55
55
56
56
57
60
60
63
64
PRECAUTIONS - 35
Advertisement
Related Manuals for Smeg C92GMX2
Summary of Contents for Smeg C92GMX2
-
Page 1: Table Of Contents
Instructions for the installer Using the accessories We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions • This appliance may only be... - Page 2 they are constantly supervised. lid or a blanket. • Keep children under the age of • The appliance becomes very 8 away from the appliance hot during use. Take care never when it is in use. to touch the heating elements •...
- Page 3 AVAILABLE) OR NEAR THE damaged, contact technical APPLIANCE. support immediately to arrange • DO NOT USE AEROSOLS IN for it to be replaced in order to THE VICINITY OF THIS avoid possible hazards. APPLIANCE WHILST IT IS IN • WARNING: A gas cooking USE.
- Page 4 into the side guides. The bottom as a support for mechanical safety locks that cooking. prevent them from being • If you wish to use greaseproof removed must face downwards paper, place it so that it will not and towards the back of the interfere with the hot air oven.
-
Page 5: Installation
• Never use the oven door to ventilation. lever the appliance into place • The settings for this appliance when fitting. are shown on the gas setting • Avoid exerting too much label. pressure on the door when • Have the gas connection open. -
Page 6: Appliance Purpose
• Use cables that can withstand equipped with an updated version of the system, and as such, all that appears on the temperatures of at least 90°C. display may differ from those in the manual. • The tightening torque of the Manufacturer’s liability screws of the terminal supply The manufacturer declines all liability for... -
Page 7: Information For European Control Bodies
light sources. Plastic packaging Danger of suffocation • Do not let children play with the plastic bags. Information for European Control Bodies • The light sources contained in the appliance Fan forced mode are declared suitable for operation at the ECO function used to define the energy ambient temperature ≥300°C and intended efficiency class complies with the specifications for use in high temperature applications such... -
Page 8: Description
DESCRIPTION General description 1 Upstand 7 Fan 2 Hob 8 Auxiliary oven light 3 Control panel 9 Auxiliary oven seal 4 Main oven light 10 Auxiliary oven door 5 Main oven seal 11 Storage compartment 6 Main oven door Frame shelf AUX = Auxiliary Burner SR = Semi-rapid Burner R = Rapid Burner... -
Page 9: Control Panel
Control panel 1 Hob burner knobs Other parts For lighting and adjusting the hob burners. Press Shelves and turn the knobs anti-clockwise to The appliance features shelves to position trays order to light the relative burners. Turn the knobs and racks at different heights. The insertion to the zone between the maximum heights are indicated from the bottom upwards (see General description). - Page 10 Centres. Use only original accessories Useful for supporting containers with food supplied by the manufacturer. during cooking. Deep tray Trivet Useful when using small cookware. Trivet Useful for collecting fat from foods placed on the rack above and for cooking pies, pizzas, baked desserts, biscuits, etc.
-
Page 11: Use
Preliminary operations the food which is being cooked. See General safety instructions. • Remove any protective film from the outside or inside of the appliance, including accessories. • Remove any labels (apart from the technical data plate) from the accessories and Trivets and reduction pan supports shelves. -
Page 12: Using The Storage Compartment (Where Present)
Keep the knob pressed in longer. Switching on the auxiliary oven In case of an accidental switching off, a Turn the temperature/functions knob to the safety device will be tripped, cutting off required temperature, between 50°C and the gas supply, even if the gas cock is 245°C, or to the required function (at the maximum temperature). -
Page 13: Digital Programmer
TURBO Increase key Allows quick cooking on multiple Setting the time shelves without mixing the aromas. Perfect for large volumes that call for If the time is not set, the oven will not intense cooking. switch on. CIRCULAIRE On the first use, or after a power failure, the The heat is distributed quickly and digits will be flashing on the... - Page 14 9. At the end of cooking the heating elements turns off, the symbol flashes and the buzzer will be deactivated. On the display, the sounds. 6. To turn the buzzer off, simply press one of symbol turns off, the symbol flashes and the programmer clock buttons.
-
Page 15: Cooking Advice
Modifying the set data value to optimise cooking. 1. Press the clock key Advice for cooking desserts/pastries and biscuits 2. Use the increase and decrease • Use dark metal moulds: They help to absorb keys to set the required minutes. the heat better. -
Page 16: Cooking Information Table
Cooking information table Weight Temp. Time Food Function Shelf (Kg) (°C) (minutes) Lasagne 3 - 4 STATIC 220 - 230 45 - 50 Pasta bake 3 - 4 STATIC 220 - 230 45 - 50 Veal roast TURBO/CIRCULAIRE 180 - 190 90 - 100 Pork loin TURBO/CIRCULAIRE... -
Page 17: Cooking Information Table (Auxiliary Oven)
Weight Temp. Time Food Function Shelf (Kg) (°C) (minutes) Sponge CIRCULAIRE 150 - 160 55 - 60 cake Rice TURBO/CIRCULAIRE 55 - 60 pudding Brioches CIRCULAIRE 30 - 35 The times indicated in the table do not include preheating times and are provided only as a guide. Cooking information table (auxiliary oven) Weight Temp. -
Page 18: Knobs
remove the door and place it on a tea towel. them thoroughly and return them to the hob. To remove the door proceed as follows: The continuous contact between the 1. Open the door completely and insert two pan supports and the flame can cause pins into the holes on the hinges indicated in modifications to the enamel over time in the figure. - Page 19 1. Lock the door in place using the special 5. Remove the intermediate glass unit by lifting pins. it upwards. 2. Release the two rear pins of the internal glass panel by pulling the rear part of the panel gently upwards, following the movement indicated by the arrows 1.
-
Page 20: Cleaning The Oven Cavity
7. Use absorbent kitchen roll. In case of Drying stubborn dirt, wash with a damp sponge Cooking food generates moisture inside the and neutral detergent. appliance. This is a normal phenomenon and 8. Reinstall the intermediate glass unit and does not affect the appliance’s operation in any reposition the internal glass panel. -
Page 21: Vapor Clean (On Some Models Only)
self-cleaning panels (where fitted), which rack/tray support frame. were previously removed, separately in warm water and a small amount of detergent. Vapor Clean cycle setting 1. Turn the functions knob to symbol (where present). 2. Turn the temperature knob to the symbol. -
Page 22: Installation
5. Replace the light bulb with one of the same Power voltage type (40 W). Danger of electrocution 6. Refit the cover. Ensure the moulded part of the glass (A) is facing the door. • Wear protective gloves. 1. Completely remove all accessories from inside the oven. -
Page 23: Positioning
thread (ISO 228-1). walls (max. 50 °C) • The hose is not under traction or tension and Positioning has no kinks or twists • The hose is not in contact with sharp objects See General safety instructions. or sharp corners •... - Page 24 comply with the applicable standard. comply with the applicable standard. Carefully screw the connector 3 to the gas Carefully screw the hose connector 3 to the connector 1 of the appliance, placing the seal 2 appliance’s gas connector 1 (½” thread ISO between them.
- Page 25 Extraction of the combustion products Replacing nozzles The combustion products may be extracted by means of hoods connected to a natural draught chimney whose efficiency is certain or via forced extraction. An efficient extraction system requires precision planning by a specialist qualified in this area and must comply with the positions and clearances indicated by the applicable standards.
-
Page 26: Gas Types And Countries
(depending on the model) until the correct spindle clockwise all the way. minimum flame is achieved. Following adjustment to a gas other Refit the knob and verify that the burner flame is than the one originally set in the factory, stable. - Page 27 3 Natural Gas G25.1 - 25 mbar Rated heating capacity (kW) Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) (F1) (F3) (F3) Reduced flow rate (W) 1200 4 Natural Gas G2.350 - 13 mbar Rated heating capacity (kW) 1.75 Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) (F3) (F3)
- Page 28 Appliance dimensions Assembling the upstand The upstand must always be positioned and secured correctly on the appliance. 1. Loosen the 2 screws (A) on the back of the hob using a screwdriver (only loosen the outermost ones). 2. Place the upstand on the hob. 3.
-
Page 29: Electrical Connection
3. Assemble the fastening bracket. 7. Move the bracket onto the wall and mark the position of the holes to be drilled in the wall. 4. Align the base of the hook on the fastening bracket with the base of the slot on the wall fastening plate. -
Page 30: Instructions For The Installer
2. Gently rotate the plate and remove it from its 380-415 V 2N~ seat. 4 x 1.5 mm ² four-core cable 220-240 V 2~ 3 x 2.5 mm ² three-core cable 220-240 V 3~ 4 x 1.5 mm ² four-core cable 3. - Page 31 on all connections. DO NOT use naked flames to search for leaks. • Turn on all the burners separately and at then all together to make sure that the gas valve, burner and ignition are working properly. • Turn the burner knobs to the minimum position and check that the flame is stable for each individual burner and all the burners together.
