Audio - NEC MultiSync V554Q-R User Manual

ROTATION
IMAGE FLIP
NONE
H FLIP
V FLIP
180° ROTATE
OSD FLIP
SPECTRAVIEW ENGINE
RESET

AUDIO

VOLUME
BALANCE
BALANCE
SURROUND
EQUALIZER
TREBLE
BASS
AUDIO INPUT
MULTI PICTURE AUDIO
LINE OUT
AUDIO DELAY
AUDIO DELAY
DELAY TIME
RESET
*1: This function depends on which Option Board you are using.
Shows the inverse image right-left, up-down or rotation.
Press + or - to select.
NOTE: This function is not available when [MOTION] in [SCREEN SAVER] is [ON].
NOTE: When the [ASPECT] is set to [DYNAMIC], the image will be changed to [FULL] image before [ROTATE]
starts.
When selecting [IMAGE FLIP] (except for [NONE]), the following functions are disabled: [MULTI PICTURE
MODE], [TEXT TICKER], [STILL], POINT ZOOM and [TILE MATRIX].
When the input signal is interlaced, the image may be distorted.
Normal mode.
The image inverts right-left.
The image inverts up-down.
The image rotates 180 degrees.
Determines the OSD display direction.
If [ON] is selected, the OSD will be inverted depending on the image status.
Select [ON] to activate [SPECTRAVIEW ENGINE] (see
Resets all [PICTURE] settings back to factory settings except for [SPECTRAVIEW ENGINE] and [PICTURE
MODE].
Increase or decrease output volume level.
Select [STEREO] or [MONO] for the audio output.
If you select [STEREO], adjust the L/R volume balance.
Press the + button to move the stereo sound image to right.
Press the - button to move the stereo sound image to left.
NOTE: [BALANCE] is not available if [MONO] is set at [STEREO]/[MONO].
Artificial surround sound.
NOTE: [LINE OUT] is disabled when this function is set to [ON].
Accentuate or reduce the high frequency range of audio signals.
Press the + button to increase [TREBLE].
Press the - button to decrease [TREBLE].
Accentuate or reduce the low frequency sound.
Press the + button to increase [BASS].
Press the - button to decrease [BASS].
Selects the audio input source: [HDMI1], [HDMI2], [HDMI3], [DisplayPort1], [DisplayPort2], [IN], [MP],
[OPTION]* .
1
Selects which audio source to use when [MULTI PICTURE] is enabled.
When either picture number is selected, the sound of that picture is output.
Selecting [VARIABLE] enables control of the line out level with the VOLUME button.
Activate a delay time to output the audio signal. The [DELAY TIME] can be set between 0 and 100 milliseconds.
Set to [ON] to activate this function.
Resets all [AUDIO] options back to factory settings, except for [VOLUME].
page 28).
English-34
