TEXT TICKER*
*
NOTE: When [TEXT TICKER] is set, [MULTI PICTURE MODE] and STILL are not available.
1,
2
[TEXT TICKER] is released if following menu is activated: [MULTI PICTURE MODE], [TILE MATRIX], [SCREEN
SAVER], [IMAGE FLIP], [SUPER] in [INPUT CHANGE].
When this function is active, POINT ZOOM and STILL are not available.
MODE
Enables Text Ticker and allows you to set Horizontal or Vertical direction.
POSITION
Selects the location of the Text Ticker on the screen.
SIZE
Determines the size of the Text Ticker in relationship to the overall screen size.
DETECT
Enables auto-detection of the Text Ticker.
INPUT SELECT
Set input signal for [PICTURE1], [PICTURE2].
INPUT DETECT*
Selects the method of input detection the monitor uses when more than one signal source is connected.
4
NOTE: When [SUPER] is selected within [INPUT CHANGE], this function cannot be changed.
[INPUT DETECT] is released if [HUMAN SENSOR] is activated while [INPUT DETECT] is active.
NONE
The Monitor will not search for signals at the other video input ports.
FIRST DETECT*
*
When the current video input signal is not present, the monitor searches for a video signal from another video
2,
3
input port. If a video signal is present in the other input, the monitor switches from the current video source to this
active video source automatically.
The monitor will not look for any other video signals while the current video source is present.
LAST DETECT*
2,
*
3
When the monitor is reproducing a signal from the current video source and a new second video source is
supplied to the monitor, the monitor will automatically switch to the new video source. When the current video
input signal is not present anymore, the monitor searches for a video signal from any other video input. If a video
signal is present in the other input, the monitor switches from the current video source to this active video source
automatically.
CUSTOM DETECT*
2
Sets the priority of input signals.
When [CUSTOM DETECT] is selected, the monitor searches on preset inputs only.
NOTE: Priority of an option input signal is only available in [PRIORITY3], except for a slot 2 type PC option.
If you set [DisplayPort1] to [Priority 1] or [2] or [3], you cannot set [OPTION] (slot 2 type PC option (DP)) to
any priority settings. If you set [OPTION] (slot 2 type PC option (DP)) to [Priority 1] or [2] or [3], you cannot set
[DisplayPort1] to any priority settings.
INPUT CHANGE
Sets input change speed. If [QUICK] is set, speed of changing input is faster but this setting may cause image
distorted while switching signals.
Selecting [SUPER] enables high-speed switching between two preset signals.
NOTE: Depending on the Option Board you use, [SUPER] may not be available.
When [SUPER] is active, [MULTI PICTURE MODE], [TEXT TICKER], STILL, POINT ZOOM are not available.
TERMINAL SETTINGS
DisplayPort
Selects the DisplayPort mode [1.1a] or [1.2].
[DisplayPort 1.1a] is selected, [SST] is set automatically.
[DisplayPort 1.2] is selected, set [SST] or [MST].
[DisplayPort 1.2] should be selected when using Multi-Stream Transport. Multi-Stream Transport requires a
corresponding display card. Contact your supplier for limitations of this function.
NOTE: [MST] is not available with DisplayPort IN2 signal input.
BIT RATE
[DisplayPort 1.1a] is selected at [DisplayPort], [HBR] is set automatically.
[DisplayPort1.2] and [SST] are selected at [DisplayPort], set [HBR] or [HBR2].
[DisplayPort1.2] and [MST] are selected at [DisplayPort], [HBR2] is set automatically.
HDMI
Selects [MODE1] or [MODE2].
MODE1: Max resolution is 4096 x 2160 (30 Hz)
MODE2: Max resolution is 4096 x 2160 (60 Hz)
VIDEO LEVEL
RAW: For computer settings. Show all input signals of 0-255 gray levels.
EXPAND: For audio-visual equipment settings. Expands the input signals from 16-235 gray levels to 0-255 gray
levels.
AUTO: Automatically sets input signals by adjusting connected equipment.
NOTE: This function is available only in [HDMI] or [DisplayPort] or [OPTION] and is selected at [INPUT SIGNAL].
SIGNAL FORMAT
Selects the color space setting for the HDMI/DisplayPort signal. If [SLOT2 CH SETTING] is [2CH], this function is
grayed out.
RESET
Resets [MULTI INPUT] options back to factory settings, except for [INPUT DETECT] (priority of input signals
only), [INPUT CHANGE] ([INPUT1] and [INPUT2]), [INPUT SELECT], [PICTURE ASPECT] and [BIT RATE].
*1: This function is released when selecting [SUPER] in [INPUT CHANGE], [MOTION] in [SCREEN SAVER], [TILE MATRIX] and [IMAGE FLIP] except for [NONE].
*2: When you select [OPTION] for multi picture input, this function depends on which Option Board you are using.
*3: Except for MP.
*4: Depending on the device, it may not be detected correctly.
English-37
