MAIN COMPONENTS

1. Pressure switch
2. Regulator
3. Output pressure gauge
4. Tank pressure gauge
5. Safety valve
6. Return valve
7. Drain cock
8. Feet
9. Air reciever
10. High pressure pipe
11. Pump
12. Shroud
Model
Power
Voltage
Motor Poles
Rated Speed
Delivery
Discharge Pressure
Tank Capacity
Dimensions
Net Weight
Noise Specification
WWW.SGS-ENGINEERING.COM
SC8H
1 kW / 1.1 HP
230 V @ 50 Hz
2 P
3450 rpm
5.5 cfm
116 psi / 0.8 MPa
8 L
510 x 250 x 510 mm
16 kg
LWA 97dB
