- Page 1 SC100V AIR COMPRESSOR OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
-
Page 2: Specification
SPECIFICATION ITEM DATA Model SC100V Power 2.2 Kw / 3 HP Voltage 230 V Frequency 50 Hz Motor Poles Rated Speed 2850 rpm Current 10 A Delivery 14.6 CFM Discharge Pressure 115 PSI / 0.8 MPa Restart Pressure 80 PSI / 0.55 MPa... -
Page 3: Main Components
MAIN COMPONENTS 1. Main compressor 2. Pressure switch 3. Outlet Valve 4. Regulating Valve 5. Pressure gauge 6. One-way Valve 7. Drain cock 8. Wheels 9. Air tank 10. Safety valve 11. Fan cover PAGE 3... -
Page 4: Warning Symbols
Air and condensation water can burst from the compressor when the drain plug is removed. Wear a safety goggles and ear protectors when using this compressor. This compressor produces a high sound level during operation. Ear protection should be worn. WWW.SGS-ENGINEERING.COM PAGE 4... -
Page 5: Safety Precautions
SAFETY PRECAUTIONS TRAINING: Prior to use, all users must become familiar with the instructions given in this manual. In particular, become familiar with the ON/OFF control for stopping the compressor in the event of an emergency. ALWAYS USE EYE PROTECTION: When operating the air com- pressor, always use eye protection such as goggles, and make sure that other people in the work area are also using eye protection. - Page 6 STAY ALERT: Watch what you are doing, use common sense, and do not operate the air compressor when you are tired. The air compressor should not be used if you are under the influence of alcohol, drugs or any medication that makes you drowsy. WWW.SGS-ENGINEERING.COM PAGE 6...
- Page 7 SAFETY PRECAUTIONS DISCONNECT THE AIR COMPRESSOR: Always disconnect the air compressor from the mains power supply and decompress before performing maintenance, changing any parts and when not in use. MAINS POWER CABLE PRECAUTIONS: Never pull on the cable when removing the plug from the mains socket, or lift the compres- sor by the mains cable.
- Page 8 DISPOSAL INFORMATION: The air compressor should be disposed of in a safe an environmentally friendly manner. Contact your local Council for disposal assistance. DO NOT WELD TO THE PRESSURE VESSEL: Do not weld or modify the pressure vessel in any manner. WWW.SGS-ENGINEERING.COM PAGE 8...
- Page 9 ASSEMBLY - Use a spanner to attach the wheels to the compressor. - Use the washers and spring washer in the positions shown. Insert the support foot into the position shown. PAGE 9...
-
Page 10: Preparation For Starting
(2.) 3. Screw both the air filters in either side before starting the compressor. (3.) 4. Set the compressor in a clean, dry and ventilated area. 5. Keep voltage within ±4% of the rated value. WWW.SGS-ENGINEERING.COM PAGE 10... - Page 11 5. Keep the oil level in the red circle of the oil glass sight win- dow. You can purchase compres- sor oil from our website at: www.sgs-engineering.com 6. Open the outlet valve, set the power switch knob to posi- tion “on” and let the compres-...
-
Page 12: Operation And Adjustment
This is a necessary condition before restarting or the motor will be damaged. The rated pressure can be altered by turning the adjusting screw. WWW.SGS-ENGINEERING.COM PAGE 12... - Page 13 OPERATION AND ADJUSTMENT PRESSURE GAUGES There are two pressure gauges on the compressor. 1. The pressure gauge on the RIGHT shows the current pres- sure in the reservoir tank. 2. The pressure gauge on the LEFT shows the ‘user set’ outlet pressure.
- Page 14 4. Always vent the compressor after each use by turning the regulator knob fully anticlock- wise. 5. Once the compressor is vent- ed, remove any condensation from inside the tank by unscrew- ing the bleed nipple. WWW.SGS-ENGINEERING.COM PAGE 14...
-
Page 15: Maintenance
MAINTENANCE 1. Before any maintenance operation stop the air compressor, cut off the power supply and discharge all air in the air tank. 2. Clean crank case and renew lubri- cating oil after the first 10 working hours. Check the oil level through the oil level sightglass (1.) after every 20 working hours and replenish if neces- sary- you can replenish by unbolting... - Page 16 Rinse and let the filters dry com- pletely before refitting. 5. Make sure that the filters and filter covers are replaced into position. If the filters are damaged, you must replace them. WWW.SGS-ENGINEERING.COM PAGE 16...
- Page 17 MAINTENANCE CHECK THE NON-RETURN VALVE (EVERY 6 MONTHS) If the reservoir pressure decreases for no apparent reason, it is possible that the non-return valve is leaking. To check: 1. Make sure that the reservoir is not under pressure and the compressor is switched OFF.
- Page 18 Leave this compressor for a good while until you reset it. If the compressor turns off again on re-set you should not keep running it as it may be damaged and the system may be unsafe. WWW.SGS-ENGINEERING.COM PAGE 18...
-
Page 19: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE ACTION Motor unable to run, Fault in line or insufficient Check the line running slow or getting voltage Replace the wire Power wire too thin or long Repair or replace Fault in pressure switch Repair or replace Fault in motor Check and repair Sticking of main compres-... -
Page 20: Replacement Parts Diagram
REPLACEMENT PARTS DIAGRAM WWW.SGS-ENGINEERING.COM PAGE 20... -
Page 21: Parts List
PARTS LIST ITEM PART ITEM PART Bolt M6x25 90’ Elbow Cylinder Head Connector Cylinder Head Gasket 90’ Elbow - T pc Cylinder Head Air Filter Valve Plate Stator Valve Plate Gasket Rotor Y-Connect Bearing Cylinder Wave Washer D35 Cylinder Gasket Brushes 1 Piston Ring Brushes 2... - Page 22 SGS Engineering (UK) Ltd West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd Air Compressor TYPE OF EQUIPMENT: SC100V PART NUMBER: PARAMETERS: Rated Voltage...
