- Page 1 USER MANUAL SILENT1 PORTABLE AIR CONDITIONER Thank you for choosing electriQ Please read this user manual before using this innovative Air Conditioner and keep it safe for future reference. Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals...
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS ............3 OPERATION ................8 REMOTE CONTROL .............. 8 EMPTYING THE INTERNAL WATER TANK ......10 MANUAL DRAINAGE: ............10 MAINTENANCE ..............11 CLEANING ................11 END OF SEASON MAINTENANCE ........11 TROUBLESHOOTING............12 APPENDIX ................13 TECHNICAL DATA ............... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Important! • Carefully read the instructions before operating the unit • This appliance is for indoor use only. • Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed outlet. • Installation must be in accordance with regulations of the country where the unit is used. - Page 4 • R290 refrigerant gas complies with European environmental directives. • R290 has a low GWP (Global Warming Potential) of 3. • The air conditioner contains about 2 0 g of R290 refrigerant gas. • Do not use or store in an unventilated space with an area smaller than 1 m per unit.
- Page 5 FEATURES AND PARTS LIST FEATURES Self-evaporative system - no external water tank needed Designer inspired luxury model Bright LED screen, indicates temperature and operation mode On/Off timer function – allows you to choose when the unit operates Compressor protection technology PARTS LIST Control panel Top cover...
- Page 6 INSTALLATION Warning: Before using this unit, please keep it upright for at least 3-4 hours. This unit can easily be moved from one room to another. While moving the unit please note that it must always be kept upright and then placed on an even surface.
- Page 7 NOTES: • The window kit is only designed to be installed with sliding or sash windows or doors. The window kit is not designed or to be used with any other style of windows. • The fish tail adaptor can be used without the slide bar with most windows / doors. •...
-
Page 8: Operation
OPERATION This portable air conditioner boasts 3 modes: Cooling, Dehumidifying and Fan. The fan has two speeds: high and low. Temperature range settings are: 16-31 . The unit will also display operating function, temperature, fault diagnostics and protective functions on the display. 1:Swing Button 2:Timer Button 3:Fan Speed Button... -
Page 9: Remote Control
REMOTE CONTROL The air conditioner can be controlled with the remote control. Two AAA-batteries are required to use the remote control. POWER : Press the POWER button to turn the machine on and off. MODE : Press the MODE button to switch between cooling, fan, Dehumidify modes. -
Page 10: Emptying The Internal Water Tank
EMPTYING THE INTERNAL WATER TANK MANUAL DRAINAGE: When the internal water tank is full the unit will stop working. Shut off the unit and unplug. Try not to move the model abruptly as this may cause the water in the internal tank to spill out. Place a tray under the water plug or place the unit in a drainage area. -
Page 11: Maintenance
MAINTENANCE CLEANING PLEASE TURN OFF THE UNIT AND UNPLUG FROM THE MAINS BEFORE CLEANING OR PERFORMING ANY MAINTENANCE CLEAN THE SURFACE Clean the surface of the machine with a wet soft cloth. Do not use chemicals, such as benzene, alcohol, gasoline, etc;... -
Page 12: Troubleshooting
TROUBLESHOOTING Do not repair or disassemble the air conditioning. Unqualified repair will invalidate the warranty and may lead to failure, causing injuries and property damage. Only use it as directed in this user manual and only perform operations advised here. Problems Reasons Solutions... -
Page 13: Appendix
APPENDIX Disposal: Do not dispose this product as unsorted municipal waste. Collection of such waste must be handled separately as special treatment is necessary. Recycling facilities are now available for all customers at which you can deposit your old electrical products. Customers will be able to take any old electrical equipment to participating civic amenity sites run by their local councils. - Page 14 UK SUPPORT www.electriQ.co.uk/support Please, for your own convenience, make these simple checks before calling the service line. If the unit still fails to operate call the number below, or complete the online form. 0871 620 1057 1. Has the unit been standing upright for at least 2 hours? 2.
