Danger Symbols; Environmental Considerations - Unitronics Vision OPLC V570-57-C30B Installation Manual

Vision™ OPLC™ V570-57-C30B, V570-57-T40B
Removable
Memory
Storage
Operand Types
Data Tables
Additional product documentation is in the Technical Library, located at www.unitronics.com, and on
the Unitronics' Setup CD.
Technical support is available at the site, and from support@unitronics.com.
Standard Kit Contents
Vision controller
3 pin power supply connector
5-pin CANbus connector
CANbus network termination resistor

Danger Symbols

When any of the following symbols appear, read the associated information carefully.
Symbol Meaning
Danger
Warning
Caution Caution
Before using this product, the user must read and understand this document.
All examples and diagrams are intended to aid understanding, and do not guarantee operation.
Unitronics accepts no responsibility for actual use of this product based on these examples.
Please dispose of this product according to local and national standards and regulations.
Only qualified service personnel should open this device or carry out repairs.
Failure to comply with appropriate safety guidelines can cause severe injury or property damage.
Do not attempt to use this device with parameters that exceed permissible levels.
To avoid damaging the system, do not connect/disconnect the device when power is on.

Environmental Considerations

Do not install in areas with: excessive or conductive dust, corrosive or flammable gas,
moisture or rain, excessive heat, regular impact shocks or excessive vibration, in accordance
with the standards given in the product's technical specification sheet.
Ventilation: 10mm space required between controller's top/bottom edges & enclosure walls.
Do not place in water or let water leak onto the unit.
Do not allow debris to fall inside the unit during installation.
Install at maximum distance from high-voltage cables and power equipment.
2
An SD card enables you to store datalogs, Alarm history, Data Tables; export to
Excel/.csv, backup Ladder, HMI & OS and use this data to 'clone' PLCs.
For more data, refer to the SD topics in the VisiLogic Help system.
;
Memory Bits 8192 Memory Integers 4096 registers 16-bit, 512 Long Integers,
32-bit, 256; Double Word, 32-bit unsigned, 64; Memory Floats, 32-bit, 384;
Timers, 32-bit, 32; Counters, 16-bit.
120K (Dynamic)/ 192K (Static) enables application recipes and data logging.
Description
The identified danger causes physical and property damage.
The identified danger could cause physical and property damage.
Use caution.
Battery (not installed)
Programming cable + RS232 adapter
Mounting brackets (x4)
Rubber seal
Unitronics' Setup CD
Installation Guide
