DEMO MANUAL DC2543B
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 8 C2, C3, C47, C49, C56, C57, C58, C59 CAP , 1210 2.2µF 10% 100V X7R
3 4 C4, C5, C15, C126
4 2 C6, C7
5 1 C8
6 2 C9, C26
7 2 C17, C28
8 11 C18, C19, C20, C21, C29, C66, C67
9 C68, C73, C74, C65
10 2 C27, C50
11 2 C52, C53
12 1 C54
13 1 C55
14 3 D1, D2, D3
15 1 D6*
16 2 D9, D10
17 1 L2
18 1 Q1
19 3 Q3, Q6, Q7
20 4 Q9, Q10, Q11, Q23
21 1 Q22
22 1 RS1
23 1 RS2
24 2 R1, R7
25 1 R2
26 4 R5, R10, R24, R32
27 4 R9, R13, R17, R28
28 1 R16
29 1 R18
30 1 R26
31 1 R27
32 1 R29
33 1 R30
34 1 R31
35 1 U1
36 1 U2
6
PART DESCRIPTION
CAP , 33µF 20% 80V ELEC
CAP , 0603 0.1µF 10% 100V X7R
CAP , 0805 4.7µF 10% 16V X7R
CAP , 0603 0.22µF 10% 25V X7R
CAP , 0603 0.47µF 10% 25V X7R
CAP , 0805 2.2µF 10% 50V X7R
CAP , 1210 10µF 10% 50V X7R
CAP , 0603 1µF 10% 50V X5R
CAP , 1210 22µF 10% 25V X5R
CAP , 0603 47nF 10% 25V X7R
CAP , 0603 470pF 10% 50V X7R
DIODE, SCHOTTKY
DIODE, SCHOTTKY
DIODE, ZENER
IND, 68µH
XSTR, N-CHANNEL MOSFET
XSTR, N-CHANNEL MOSFET
XSTR, N-CH 40V 14A TO-252
TRANSISTOR., SOT-23
RES., CHIP , 0.005, 1%, 2010
RES, 2010 0Ω JUMPER
RES, 0603 1kΩ 1%
RES, 0603 2.2Ω 5%
RES, 0603 0Ω JUMPER
RES, 0603 10kΩ 1%
RES, 0603 60.4kΩ 1%
RES, 0603 100kΩ 1%
RES, 0603 154kΩ 1%
RES, 0603 20kΩ 5%
RES, 0603 80.6kΩ 1%
RES. 2010 1Ω 1% 1W
RES, 0603 100Ω 5%
IC, LTC7820EUFD, QFN 4mm × 5mm
IC, LTC3630AEMSE
MANUFACTURER/PART NUMBER
PANASONIC EEHZA1K330P
MURATA GRM32DR72A225KA12
MURATA GRM188R72A104KA35D
MURATA GRM21BR71C475KA73K
MURATA GRM188R71E224KA88D
MURATA GRM188R71E474KA12D
TDK C2012X7R1H225K125AC
MURATA GRM32ER71H106KA12L
MURATA GRM188R61H105K
AVX 12103D226KAT2A
AVX 06033C473KAT2A
MURATA GRM188R71H471KA01D
CENTRAL SEMI. CMDSH-4E TR
ON SEMI, NRVTSAF5100E
CENTRAL SEMI. CMHZ5236B TR
COILCRAFT., LPS6225-683MRB
INFINEON BSC027N06LS5
INFINEON BSC032N04LS
VISHAY SUD50N04-8M8P-4GE3
FAIRCHILD., BSS123L
VISHAY, WSL20105L000FEA
VISHAY WSL201000000ZEA9
VISHAY CRCW06031K00FKEA
YAGEO RC0603JR-072R2L
VISHAY CRCW06030000Z0EA
NIC NRC06F1002TRF
VISHAY CRCW060360K4FKEA
VISHAY CRCW0603100KFKEA
YAGEO RC0603FR-07154KL
VISHAY CRCW060320K0JNEA
YAGEO RC0603FR-0780K6L
IRC LRC-LR2010-01-1R00-F
VISHAY CRCW0603100R0JNEA
ANALOG DEVICES, ALTC7820EUFD#PBF
ANALOG DEVICES, LTC3630EMSE#PBF
