Installation and Operating Instruction for B.E.G. – Occupancy detector PD4-M-1C-C-SM / FC / FM
1. Mounting preparation
Work on the 230 V mains supply may only be carried out
by qualified professionals or by instructed persons under
the direction and supervision of qualified skilled electrical
personnel in accordance with electredechnical regulations.
Disconnect supply before installing!
The device is not suited for safe disconnection of the
mains supply.
When in Master/Slave mode of operation, the Master-
appliance must always be installed at the location where
there is least daylight.
3a. Hardware configuration SM
Position LED's
1 2
40
LED 1 green
LED 2 red
LED 3 white
4a. Position DIP-switches SM
1
40
OFF
Surface
VA
LED
mounting
DIP 1 Fully automatic/semi automatic mode
DIP 2 LED ON/OFF
DIP 3 Change between corridor mode and standard
mode
The DIP switch settings are using the remote control.
overriden
2a. Installation of the LUXOMAT
open
3b. Hardware configuration FC
Position LED's and potentiometers
Potentiometer 1 Lux
LED 1 green
LED 2 white
Potentiometer 2 Time
LED 3 red
3
4b. Position DIP-switches
2 3
ON
OFF ON
HA
DIP
COR
DIP 1
DIP 2
DIP 3
The DIP switch settings are
PD4-M-1C-C
®
PD4-M-1C-C-SM
®
The detector must be installed on a
solid and level surface. The circular
cover ring must be removed prior to
close
assembly. To do this, twist the lens
anticlockwise through approxi-
mately 5° and lift off.
Having connected up the wires
in accordance with regulations,
secure the detector with 2 screws.
After installation replace the lens
and lock (turn clockwise). Mains to
be connected.
1 2 3
1 2
Potentiometer 1 Lux
Potentiometer 2 Time
2
1
false ceiling
mounting
Fully automatic/semi automatic mode
LED ON/OFF
Change between corridor mode and standard mode
overriden using the remote control.
2b. Installation of the LUXOMAT
Having connected up the cables in accordance with
regulations, the detector is inserted into the opening as
shown in the drawing opposite and fixed into position with
the assistance of the spring clip.
5. DIP switch functions
DIP- ON
switch
1 Semi automatic mode
2 LED OFF
3 Corridor mode
OFF ON
1
2
DIP
3
Corridor function:
After deactivation by an external push button,
the detector switches off and returns to automatic mode after 5 sec.
The DIP settings are enabled again by:
• Adjusting the DIP switches when closed
• Reset with test sun setting at the potentiometers
• Reset when open
3
DIP
OFF
ON
GB
® PD4-M-1C-C-FC
The detector has been designed and
developed specifically for installation
in suspended ceilings.
A circular opening of diameter
68 mm must first of all be produced
in the ceiling.
OFF
Fully automatic mode
LED ON
Standard mode
