INSTALLATION AND CARE GUIDE
MODERN ONE PIECE TOILET
Compliance with the following Plumbing Codes & Standards:
• 2015 Uniform Plumbing Code
• 2018 International Plumbing Code
• WaterSense Certified Toilet
• CSA B45.5 / IAPMO Z124-2017- Plastic Plumbing Fixtures
ICC
R
ICC-ES
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
WOODBRIDGE
®
®
SCC Accredited
CB-P/S
TM
LISTED
OCPS
Accrédité
CCN
Or Email: help.woodbridge@gmail.com
www.woodbridgebath.com
R
( UPC )
( IPC )
®
ANSI
ACCREDITED
ISO/IEC 17065
Product Certification Body
#1000
190611 REV. 5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Woodbridge T-0042
Summary of Contents for Woodbridge T-0042
- Page 1 • CSA B45.5 / IAPMO Z124-2017- Plastic Plumbing Fixtures SCC Accredited CB-P/S ANSI ACCREDITED LISTED ISO/IEC 17065 OCPS Product Certification Body Accrédité #1000 ICC-ES Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help.woodbridge@gmail.com 190611 REV. 5 www.woodbridgebath.com...
-
Page 2: Tools Required For Installation
WOODBRIDGE DELUXE ONE PIECT TOILET READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION. -
Page 3: Dimensions/Technical Data
WOODBRIDGE DELUXE ONE PIECT TOILET DIMENSIONS/TECHNICAL DATA 28 1/2" 14 1/4" 2 1/2" 7 1/4" 2" 1 1/2" 18" Rough-in 12" Standard IMPORTANT INFORMATION • Measurements are ± 3/8" and subject to change without notice • Please note that installer(s) must be certified or warranty will be voided. - Page 4 WOODBRIDGE DELUXE ONE PIECT TOILET WATER SUPPLY LOCATION & TECHNICAL INFORMATION Side View Back View Threaded Shunk (Water Supply Fill Valve) 15" Floor 12" Rough-in 4 1/2" 12" Standard 10" Side View You may connect water supply line to the fill valve. With this model the shut-off valve may be located anywhere outside of 41/2"...
- Page 5 IMPORTANT! Shut off main water supply prior to installation! REMOVE OLD TOILET 1. Shut off water supply line. If you do not have shut-off valve near the toilet shut off main water supply line. 2. Flush the old toilet and make sure that tank is empty. 3.
-
Page 6: Installation Instructions
WOODBRIDGE DELUXE ONE PIECT TOILET INSTALLATION INSTRUCTIONS INSTALL NEW TOILET Step 1. Lift and carefully put the toilet over the closet flange inside the outline made by template so the closet bolts can go through the mounting Bathroom holes in the toilet's base. Once the bowl is in the position... - Page 7 WOODBRIDGE DELUXE ONE PIECT TOILET TOILET SEAT ADJUSTMENT Remove the seat by placing in the vertical position and lifting off. This may require quite a bit of force so we recommend wedging palms face-up at the base of the seat to pry off. Then tighten the fittings and cover with the brushed nickel plates.
-
Page 8: Troubleshooting
WOODBRIDGE DELUXE ONE PIECT TOILET ADJUSTMENT & MAINTENANCE (DUAL FLUSH VALVE) Important Note: Flush GPF amount is factory set. No additional adjustment is required. This page is for reference only. All adjustments are already made by manufacturer. 1. BASE INSTALLATION... -
Page 9: Water Level Adjustment
WOODBRIDGE DELUXE ONE PIECT TOILET ADJUSTMENT & MAINTENACE (FILL VALVE) Important Note: Flush GPF amount is factory set. No additional adjustment is required. This page is for reference only. All adjustments are already made by manufacturer. Instructions: 95mm When valve installed, the critical level mark on fill valve (identified by C.L. -
Page 10: Maintenance And Care
Note: fill and flush valves are maintenance free. No maintenance is required. Retain these installation instructions for future reference! Thank you for using WoodBridge products! Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help.woodbridge@gmail.com... -
Page 11: Installer Information
WOODBRIDGE NOTES NOTES INSTALLER INFORMATION INSTALLER INFORMATION DATE OF INSTALL: DATE OF INSTALL: INSTALLER’S NAME: INSTALLER’S NAME: PLUMBER: PLUMBER: CONTRACTOR: CONTRACTOR: LICENSE #: LICENSE #: www.woodbridgebath.com... - Page 12 . This warranty does not WOODBRIDGE extend to plumbing or components installed by dealers, installers or Woodbridge products must be installed by a fully insured and by any party other WOODBRIDGE licensed plumber only. Installation of any our product by anyone...
- Page 13 WOODBRIDGE BID21 NON-ELECTRONIC BIDET SEAT Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time) Or Email: help@woodbridgebath.com 2020411 REV. 1 www.woodbridgebath.com...
- Page 14 WOODBRIDGE • Dimension 14 1/8" 2 5/8" 8 1/4" 17 1/8"~18 1/4"...
- Page 15 WOODBRIDGE Advantages 1. Wide water pressure range, suitable for most of regions. Water pressure：0.05MPa (dynamic)～0.8MPa (static) 0.05~0.8Mpa...
- Page 16 WOODBRIDGE Advantages 2. Slim design 2 5/8" Advantages 3.Soft close, noise-free Seat and lid are installed with soft close dampers, noise-free when opening and closing.
- Page 17 WOODBRIDGE Advantages 4.Rotate the knob to switch rear or feminine cleaning Rear cleaning Feminine cleaning (clockwise rotating) (counterclockwise rotating) Rotate the rotation angle of knob to adjust water volume Advantages 5.Nozzle self-cleaning, anti-bacterial and is removable for cleaning Self-cleaning Removable...
- Page 18 WOODBRIDGE Advantages 6. Spray nozzle with Inbreathe design,water-saving Water-saving, softer and more comfortable cleansing...
- Page 19 WOODBRIDGE Advantages 7. Spray nozzle with several holes design, softer cleansing spray nozzle with several holes design, softer cleansing Quick release 8.Quick-release system, easy installation.
