DSQD Manual
Panels and Features
DSQD Front Panel
Menu/Select
Antenna Bias
Reset Button
Menu navigation
Return to
Power LEDs
buttons
previous screen
Headphone Volume
Headphone Jack
USB Port
IR Port
Power switch
Adjustment
Channel Selector Buttons
DSQD Rear Panel
Antenna B Input
Antenna A Input
Power Inlet
50 Ohm BNC
Dante Ports
50 Ohm BNC
Antenna B
XLR Analog Output
Multi-Frame
Ethernet
Or AES3 Outputs on 2
Antenna A
Loop-thru Output
Connectors
Port
Communication
Loop-thru Output
TA3M Jacks (in Place
50 Ohm BNC
50 Ohm BNC
of The 2 Dante Ports
Shown)
4
LECTROSONICS, INC.
