Labnet TC9600-G Operation Manual page 7

MultiGene Thermal Cycler
Name Function
Function Keys
Use the function keys (F1 to F5) to activate the "button" displayed on
(F1 to F5)
the screen above the key; for example, F1 for RUN.
Directional
The four Directional Arrow keys can move the cursor into different
Arrow Keys
directions.
ENTER key
The current selection is activated or accepted when the ENTER key is
pressed.
Alphanumeric
The alphanumeric keys are usually used as number keys for the entry
Keys (0~9)
of time, temperature, password and cycle numbers. When entering a
user name or protocol name, a small screen will pop out to display the
letters after pressing the Alphanumeric keys. Press the selected key
until the desired letter is highlighted. Press the ENTER key to select
the letter or wait 5 seconds.
CLEAR key
Press CLEAR key will erase the entry in an input field.
(CE)
STOP key
By pressing STOP, the Protocol current running will be terminated.
3
Figure 1. Front Panel Overview
