VMG1312-T10C
Wireless 2x2 802.11n VDSL2 4-port Gateway with USB
Version 1.14
Edition 1, 7/2014
Quick Start Guide
User's Guide
Default Login Details
LAN IP Address
User Name
Password
www.zyxel.com
http://192.168.1.1
admin
1234
Copyright © 2014 ZyXEL Communications Corporation
