VMG1312-B10B and VMG1312-
B30B Series
Wireless N VDSL2 4-port Gateway with USB
Version 1.00
Edition 1, 11/2013
Quick Start Guide
User's Guide
Default Login Details
LAN IP Address
Login
Password
www.zyxel.com
http://192.168.1.1
admin
1234
Copyright © 2013 ZyXEL Communications Corporation
