- Page 1 CLUX-18CEC 1x8 HDMI 1.3 Splitter with CEC Function Operation Manual CLUX-18CEC...
- Page 2 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 3 Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 4: Table Of Contents
Table of Contents Introduction…………………………………………………..………. Applications……………………..…………………………....…. Package Contents…………………………..…………….....… System Requirements……...…………………..….…………..……. Features……………………………………………..……..……… Specifications..………………………………………...………...…. Operation Controls and Functions………………...……..……… Front Panel ................Rear Panel …………………………………………..….….… Connection and Installation …….…………………..…..…..…... Acronyms …….…………………..…..…..…......... -
Page 5: Introduction
1. Introduction This HDMI v1.3 Distribution Amplifier is a helpful solution for your HDMI signal distribution needs. From a single HDMI input it can transfer Deep Color (10- bit and 12-bit) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio with high bandwidth up to 225MHz (6.75Gbps) to eight HDMI outputs. -
Page 6: Features
5. Features HDMI 1.3, HDCP1.1 and DVI1.0 compliant Receiver . Deep color video up to 12bit, 1080p@(24/60)Hz. Simultaneously displays one HDMI source onto eight HDMI displays. HDCP keysets allow each output to work independently when connecting to an HDMI display. Splits a single HDMI source into eight outputs(max.) without any signal loss. -
Page 7: Specifications
6. Specifications Frequency Bandwidth 2.25Gbps (single link) Input Port 1x HDMI female port (Type A connector) Output Ports 8x HDMI female ports (signal link) HDMI Cable In 1080p 8-bit (10M), 12-bit (10M) HDMI Cable Out 1080p 8-bit (6M), 12-bit (10M) ESD Protection Human body model: ±... -
Page 8: Operation Controls And Functions
7. Operation Controls and Functions 7.1 Front Panel ① ② ③ ④ ⑤ Power Switch: This switch turns the system on and off. ① ② Power LED Indicator: This LED is green when power is on, and red when power is off. Sync LED: When an HDMI source is connected to the input port, this ③... -
Page 9: Connection And Installation
8. Connection and Installation LCD TV LCD TV LCD TV LCD TV LCD TV LCD TV LCD TV LCD TV... -
Page 10: Acronyms
Acronyms Acronym Complete Term Consumer Electronics Control Digital Theater Systems Digital Visual Interface EDID Extended Display Identification Data HDCP High-Bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface Personal Computer Printed Circuit Board SYNC Synchronize TMDS Transition Minimized Differential Signaling Transistor–transistor logic UXGA Ultra Extended Graphics Array Video Graphics Array... - Page 12 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20100125 MPM-CLUX18CEC...
