- Page 1 S1 Steel Wheelchair (CS1142SPMAG, CS1142T) Instructions for use...
-
Page 2: Parts Description
ARM REST HANDLE MAG WHEEL SIDE PANEL PARKING BRAKE REAR CALF TRANSIT STRAP WHEEL FRONT CASTOR HEEL STRAP FOOT STEPPER REST TUBE Self Propel model Transit model 18” (CS1142SPMAG) 18” (CS1142T) S1 Steel Wheelchair (Issued 2021-08 rev1) Page 2 of 12... - Page 3 preparing for use symbols These instructions should be read carefully before using the wheelchair. This product does not have a service manual. The only parts for user assembly are the footrests. A risk assessment must also be performed to assess suitability of the device for the user.
-
Page 4: Footrest Adjustment
footrest adjustment To fit the footrests, place each Adjusting footrest on the two receiver the footrest posts on the frame. Then swing the footrest inwards until it locks in position. To remove, press the chrome lever whilst swinging the footrest out (as shown right). For optimum comfort it is important to attain the correct leg position. -
Page 5: Brake Operation
brake operation Parking Brakes To apply the parking brakes, push the handle on the brake unit until locked in place. To release the brake, push the handle in the opposite direction. The brakes should always be applied when the wheelchair is stationary. Note: The brake on your wheelchair model Operating may be visually di erent from that shown. - Page 6 transfer and use Before using the wheelchair, read the safety notices below; • Do not exceed the 10º maximum gradient. Use slow speeds and do not reverse down a gradient. • Do not use on escalators. • The wheelchair is only suitable for single occupancy. •...
- Page 7 steep terrain, kerbs and steps Steep terrain: These wheelchairs are not designed for use on gradients beyond 10°. When on a slope, avoid swerving or sudden changes in movement. Over kerbs: Attendants push down on the stepper tube with a foot to raise the front castors (when mounting a kerb for example).
-
Page 8: Folding And Storage
folding and storage This wheelchair is easily foldable to minimise storage space required. The foot rests may be either be folded up and swung outwards, or removed by following the steps in footrest adjustment. Once the footrests have been moved, fold the wheelchair by grabbing the centre of the front and rear edges of the seat sling. -
Page 9: Care And Maintenance
Do not use a damaged or badly worn wheelchair. Users should routinely check for any malfunctions or changes in performance. Contact Drive DeVilbiss Healthcare Ltd or your provider to replace damaged or worn parts. • Brakes and tyres should be checked before each use, and at least once a month. -
Page 10: Specification
Self Propel Transit Model (CS1142SPMAG) (CS1142T) Maximum occupant mass 115 kg 115 kg Overall length with footrest 106 cm 88 cm Overall width 61 cm 60 cm Folded width 26 cm 26 cm Total mass 18 kg 15 kg Static stability 10°... -
Page 11: Warranty
If you have any queries or require full warranty conditions, please contact your provider. accessories and spare parts Drive DeVilbiss Healthcare Ltd provide a steel elevating footrest with some of these models. Other accessories and spare parts are also compatible with wheelchairs in this range. - Page 12 Koningin Julianaplein 10, le Verd, 2595AA, The Hague, NL Drive DeVilbiss Healthcare Ltd Sidhil Business Park, Holmfield, Halifax West Yorkshire, HX2 9TN, GB Drive DeVilbiss Healthcare Ltd provide these instructions for use and product markings. info@drivedevilbiss.co.uk www.drivedevilbiss.co.uk Service & Maintenance...
